Functional Checks; Overview; Purpose For Chapter 4; Required Equipment - GE LOGIQ P3 PRO Service Manual

GE
D 5308917-100, R
IRECTION
Chapter 4

Functional Checks

Section 4-1

Overview

4-1-1

Purpose for Chapter 4

This chapter provides procedures for quickly checking major functions of the LOGIQ P3 console,
diagnostics by using the built-in service software, and power supply adjustments.
Section
4-1
4-2
4-3
4-4
4-5
Section 4-2

Required Equipment

To perform these tests, you'll need any of the sector, linear, or convex transducers.
(normally you should check all the transducers used on the system)
