Section 8-12 Signal Cable Set (FRU P/N: 5315042 for P3 and P/N: 5388847 for
P3 BT)
8-12-0-1

Tools

• Common Phillips screwdrivers
8-12-0-2

FRU BOM

This FRU Kit P/N: 5315042 consists of following parts.
Note:This individual cables are not seperate FRUs, but are part of cable kit higher level FRU
Table 8-1 LOGIQ P3 (5315042)
Part Numbers
5265925
5262402
5273129
5266424
5272618
5269755
5268980
5264458
5267353
Table 8-2 LOGIQ P3 BT10 (5388847)
Part Numbers
5265925
5262402
5273129
5266424
5269755
5268980
5264458
5267353
5342787
5342788
5342786-1
8-12-0-3

Needed Manpower

• 1 persons, 15 minutes per cable
8-12-0-4

Preparations

• Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-12-0-5

Removal Procedure

1. Remove the covers and parts as applicable. Refer to the applicable section of this document.
2. Unplug the signal cable from both the ends.
PROPRIETARY TO GE
8
EVISION
LCD signal Cable
Docking Brd to Speaker
SATA signal Cable for HDD
Keyboard ground Cable
Fan Cable Assembly
TGC Interface Cable
Track ball 4 pin interface
Track ball 6 pin interface
Encoder PCB 15 pin interface
LCD signal Cable
Docking Brd to Speaker
SATA signal Cable for HDD
Keyboard ground Cable
TGC Interface Cable
Track ball 4 pin interface
Track ball 6 pin interface
Encoder PCB 15 pin interface
VGA cable assembly
Video Interface to MST board Cable assembly
Ethernet Cable assembly
Chapter 8 Replacement Procedures
Description
Description
