GE M
S
- K
EDICAL
YSTEMS
D
105844, R
IRECTION
EVISION
3-1-3

Installation Warnings

1.) Since the Voluson® 730 weighs approximately 136 kg (300 lb.) without options, preferably two
people should unpack it. Two people are also preferable for installing any additional items in excess
of 35 pounds (e.g. Monitor).
2.) There are no operator serviceable components. To prevent shock, do not remove any covers or
panels. Should problems or malfunctions occur, unplug the power cord. Only qualified service
personnel should carry out servicing and troubleshooting.
3.) After being transported, the unit may be very cold or hot. If this is the case, allow the unit to
acclimate before you turn it on. It requires one hour for each 2.5°C increment it's temperature is
below 10°C or above 40°C.
Equipment damage possibility. Turning the system on without acclimation after arriving at site
CAUTION
may cause the system to be damaged.
Table 3-3
°
60
55
50
45
C
°
140
131
122
113
F
hrs
8
6
4
3-1-3-1

Brake Pedal Operation

REMEMBER: If the front wheels are engaged for transportation, pressing the release
WARNING
WARNING
brake pedals (brakes on front wheels under the foot rest) once disengages the lock.
3-1-3-2

Operator I/O Panel Position

If weight is placed on the Operator I/O Panel in it's extended position the console could tip over.
The system should NOT be moved with the Operator I/O Panel extended. Move the
WARNING
WARNING
Operator I/O Panel to it's centered and locked position.
Monitor mounting mechanism may break if not properly supported (e.g. with packing
WARNING
WARNING
foam) during transportation even inside the hospital.
3-2
U
RETZTECHNIK
LTRASOUND
1
Acclimation Time
40
35
30
25
104
96
86
77
2
0
0
0
0
When pulling, moving or lifting the system,
grasp it only at the rear handle of the trolley and
the handle underneath the foot rest.
Do NOT pull or lift the system with the front handle
of the user interface (operator panel).
Figure 3-1 pulling, moving or lifting the system
20
15
10
5
68
59
50
41
0
0
0
2
WARNING
WARNING
Section 3-1 - Overview
V
® 730 S
OLUSON
0
-5
-10
-15
-20
32
23
14
5
-4
4
6
8
10
12
M
ERVICE
ANUAL
-25
-30
-35
-40
-13
-22
-31
-40
14
16
18
20
