GE
D
5308917-100, R
IRECTION
6) Loosen two screws (a,b) of flexi cable from conn board to Tx board. Refer
7) Remove flexi cable from conn board to Tx board. Refer
8) Use the screwdriver & remove four screws (1, 2, 3, 4) of connector board from the system.
Refer
Figure 8-71 on page 8-64
9) Slide the connector board out.
8-5-5-5

Mounting procedure

1.) Install the new parts in the reverse order of removal.
8-66
PROPRIETARY TO GE
8
EVISION
Figure 8-74 Loosen screws of flexi cable
Figure 8-75 Removing Flexi cable conn board
Section 8-5 - USB Cable Set (FRU P/N: 5315039)
LOGIQ P3 S
Figure 8-74 on page 8-66
Figure 8-75 on page 8-66
M
ERVICE
ANUAL
