8-4-9 Left EMI Cover (P/N: 5308964 - Not a FRU
5315111)
This is a description on how to remove and replace the Left EMI Cover.
8-4-9-1

Tools

• Common Phillips screwdrivers
8-4-9-2

Needed Manpower

• 1person, 15 minutes
8-4-9-3

Preparations

• Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-4-9-4

Removal Procedure

1) Remove Left cover. Refer
3) eight screws to be unfastened of LH -side EMI cover of Logiq P3 system.
Refer Figure 8-51 on page 8-46
2) Remove LH- side EMI cover. Refer
4) Use Screwdriver & Loose eight screws (1,2,3,4,5,6,7,8,), from LH-side EMI cover of Logiq P3 system
8-46
PROPRIETARY TO GE
8
EVISION
section 8-4-1 on page 32
6
Slide this way to remove the cover
Slide this way to reinstall the cover
7
Figure 8-51 LH side EMI cover
