Refer Figure 8-52 on page 8-47
5) Remove LH- side EMI cover of Logiq P3 system. Refer
8-4-9-5

Mounting procedure

Install the new parts in the reverse order of removal.
8-4-9-6

Functional Checkout Procedure

Functional Test
Do Visual Inspection and ensure
no scratches observed and
fitment is done properly
PROPRIETARY TO GE
8
EVISION
Figure 8-52 Loosen screw of LH- side EMI cover
Figure 8-53 Remove LH side EMI cover
Service Manual Direction 5308917-100, Section 8-4-9. Equipment passes all required
Chapter 8 Replacement Procedures
LOGIQ P3 S
Figure 8-53 on page 8-47
Debrief Script
tests and is ready for use.
