2-2-2

Electrical Requirements

NOTE: GE requires a dedicated power and ground for the proper operation of its Ultrasound
equipment. This dedicated power shall originate at the last distribution panel before the system.
Sites with a mains power system with defined Neutral and Live:
The dedicated line shall consist of one phase, a neutral (not shared with any other circuit), and a full
size ground wire from the distribution panel to the Ultrasound outlet.
Sites with a mains power system without a defined Neutral:
The dedicated line shall consist of one phase (two lines), not shared with any other circuit, and a full
size ground wire from the distribution panel to the Ultrasound outlet.
Please note that image artifacts can occur, if at any time within the facility, the ground from the main
facility's incoming power source to the Ultrasound unit is only a conduit.
2-2-2-1

LOGIQ P3 Power Requirements

Voltage Range (LOGIQ P3)
Voltage Range (LOGIQ P3 BT10)
Power
Line Frequency
Power Transients
Decaying Oscillation
PROPRIETARY TO GE
8
EVISION
Table 2-4 Electrical Specifications for LOGIQ P3
PARAMETER
100-120V
220-240V
100-240V
All applications
All applications
All applications
All applications
Chapter 2 Pre Installation
AREA
100 VAC
230 VAC ±10% (207-253 VAC)
±
10%
MAX. 425VA
50/60Hz (±2Hz)
Less than 25% of nominal peak voltage
for less than 1 millisecond for any type of
transient, including line frequency,
synchronous, asynchronous, or
aperiodic transients.
Less than 15% of peak voltage for less
than 1 millisecond.
LOGIQ P3 S M
ERVICE ANUAL
LIMITS
±
10% (90-110 VAC)
