Screen Captures

There may be times when the customer or field engineer will want to capture a presentation on the
screen. This is accomplished by first saving the image(s) to the clipboard using a Print Key.
There's no factory default print key to accomplish a secondary screen capture. However, customer may
have customize any of Print Key function. Here, take Print3 button for example, Print1 and Print3 are
the same. Therefore, screen capture should involve the following steps:
1.) Check and record any custom settings for the Print3 button.
2.) Set the Print3 button to Whole Screen, Secondary Capture.
3.) Capture the required screens to the Hard Drive or DVD-R.
4.) Restore the Print3 button to it's original settings.
7-4-1

Check and Record the P3 Key Function

Check the function of the Print3 Key in the event that the customer may have made some custom
settings.
1.) Click Utility on the keyboard.
2.) Select Connectivity from the Utilities Menu.
3.) Select the Buttons tab on the Connectivity screen.
4.) In the Physical Print Buttons field, select Print3.
The Connectivity/Buttons Screen will be displayed like the one shown in
If P3 is not set to Whole Screen, as shown in
customized settings.
5.) In the Destinations section, record the service that is displayed.
6.) In the Physical Print Buttons section, record the parameters related to the service.
7-4-2

Setting the P3 Key to Screen Capture

If the P3 Key is not set to screen capture:
1.) While on the Connect screen, with the Buttons tab displayed, go to the Destinations list.
2.) From the list select Copy To Dataflow. Press [>>] to add the selection to the Printflow View
3.) Ensure that the Physical Print Buttons section for capture Area is set to Whole Screen,
4.) The P3 Key should now be set up for whole screen capture, sending the screens to the image
7-4-3

Capturing a Screen

The following is a generic process to capture any screen from the scanner:
1.) Navigate to and display the image/screen to be captured.
2.) Press P3. This will place a snapshot of the screen on the "clipboard" displayed at the bottom
7-6
