Section 3-2 Receiving and Unpacking the Equipment
NOTE: Check the shipping container for special instructions. Verify that the container is intact. In some
cases a secondary container may be used. If so, ask the carrier for unpacking instructions.
Please carefully unpack the system, and do not dispose the package of LOGIQ P3, so that it can
CAUTION
be reused for service.
3-2-1

Moving into Position

Do not lift the unit by the keyboard. Use handle to move system.Do not tilt the unit more than 5
CAUTION
degrees to avoid tipping it over.
Equipment Damage Possibility. Lifting the console by holding covers may damage the covers.
CAUTION
Do not lift the console by holding any covers.
In general, a single adult can move the LOGIQ P3 along an even surface with no steep grades. At least
two people should move the machine when large humps, grooves, or grades are encountered. (It is
better to pull from the rear rather than push from the front of the unit). Before moving, store all loose
parts in the unit. Wrap transducers in soft cloth or foam to prevent damage.
Although LOGIQ P3 is a compact and mobile machine, two people should move it over rough surfaces
or up and down grades.
3-2-2

Adjusting System Clock

Set the system clock for the LOGIQ P3 to the local time. For procedure of adjusting the system clock,
refer to 4-5 Software Configuration Checks, in Chapter 4, FUNCTIONAL CHECKS.
PROPRIETARY TO GE
8
EVISION
Figure 3-6 Labels on Package
