Parameters: 5-** Digital In/Out - Danfoss VLT CDS302 Operating Instructions Manual

Parameter Descriptions

6.6 Parameters: 5-** Digital In/Out

6.6.1 5-** Digital In/Out
Parameter group for configuring the digital input and
output.
6.6.2 5-0* Digital In/Out Mode
5-00 Digital In/Out Mode
Option: Function:
Digital inputs and programmed digital outputs are
pre-programmable for operation either in PNP or NPN
systems.
[0] PNP Action on positive directional pulses.
*
[1] NPN
5-01 Terminal 27 Mode
Option: Function:
[0] Input Defines terminal 27 as a digital input.
*
Digital input function
No operation
Reset
Coast inverse
Coast and reset inverse
Quick stop inverse
DC-brake inverse
Stop inverse
Start
Latched start
Reversing
Start reversing
Enable start forward
Enable start reverse
Jog
Preset reference on
Preset ref bit 0
Preset ref bit 1
Preset ref bit 2
Freeze reference
Freeze output
Speed up
Speed down
Set-up select bit 0
Set-up select bit 1
Catch up
Slow down
Pulse input
Ramp bit 0
Ramp bit 1
Mains failure inverse
Day/night control
DigiPot Increase
MG34M302 - VLT
®
Operating Instructions VLT CDS302 and CDS303
5-01 Terminal 27 Mode
Option:
[1]
NOTE
This parameter cannot be adjusted while the motor is
running.
5-02 Terminal 29 Mode
Option:
6.6.3 5-1* Digital Inputs
Parameters for configuring the input functions for the
input terminals.
The digital inputs are used for selecting various functions
in the frequency converter. All digital inputs can be set to
the following functions:
Select
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[28]
[29]
[32]
[34]
[35]
[36]
[39]
[55]
®
