Parameter Descriptions
4-57 Warning Feedback High
Range:
999999.999
ReferenceFeed-
backUnit
*
3 3
4-58 Missing Motor Phase Function
Option:
[0] Disabled
[1] Trip 100 ms
[2] Trip 1000
ms
[3] Trip 100ms
3ph detec.
[5] Motor
Check
3.6.4 4-6* Speed Bypass
Some systems call for avoiding certain output frequencies
or speeds, due to resonance problems in the system. A
maximum of 4 frequency or speed ranges can be avoided.
4-60 Bypass Speed From [RPM]
Array [4]
Range:
Size related
*
4-13 RPM]
74
Function:
[ par. 4-56 - Enter the upper feedback
999999.999 limit. When the feedback
ReferenceFeed- exceeds this limit, the
backUnit] display reads Feedb High.
The signal outputs can
be programmed to
produce a status signal
on terminal 27 or 29 (FC
302 only) and on relay
output 01 or 02 (FC 302
only).
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Displays alarm 30, 31 or 32 in the event of a
missing motor phase. It is strongly
recommended to enable to avoid motor
damage.
The frequency converter does not issue a
missing motor phase alarm. Not recommended
due to risk of motor damage.
For a quick detection time and alarm in the
event of a missing motor phase.
For a slow detection time and alarm in the
event of a missing motor phase.
The frequency converter detects automatically
when the motor is disconnected and resumes
operation once the motor is connected again.
Function:
[ 0 - par. Some systems call for avoiding certain
output speeds due to resonance
problems in the system. Enter the
lower limits of the speeds to be
avoided.
®
VLT AutomationDrive FC 301/302 Programming Guide
4-61 Bypass Speed From [Hz]
Array [4]
Range:
Size related
4-62 Bypass Speed To [RPM]
Array [4]
Range:
Size related
4-63 Bypass Speed To [Hz]
Array [4]
Range:
Size related

3.7 Parameters: 5-** Digital In/Out

3.7.1 5-0* Digital I/O Mode
Parameters for configuring the input and output using
NPN and PNP.
5-00 Digital I/O Mode
Option:
PNP Action on positive directional pulses (↕). PNP systems
[0]
*
NPN Action on negative directional pulses (↕). NPN
[1]
NOTICE
Once this parameter has been changed, it must be
activated by performing a power cycle.
MG33MH02 - Rev. 2013-09-30
Function:
[ 0 - par. Some systems call for avoiding certain
*
4-14 Hz] output speeds due to resonance
problems in the system. Enter the
lower limits of the speeds to be
avoided.
Function:
[ 0 - par. Some systems call for avoiding certain
*
4-13 RPM] output speeds due to resonance
problems in the system. Enter the
upper limits of the speeds to be
avoided.
Function:
[ 0 - par. Some systems call for avoiding certain
*
4-14 Hz] output speeds due to resonance
problems in the system. Enter the
upper limits of the speeds to be
avoided.
Function:
Digital inputs and programmed digital outputs are
pre-programmable for operation either in PNP or NPN
systems.
are pulled down to GND.
systems are pulled up to + 24 V, internally in the
frequency converter.
