Table 3-33: XCZU9EG U1 to GPIO Connections (Cont'd)
XCZU9EG Schematic Net
(U1) Pin
AP14 GPIO_DIP_SW1
AM14 GPIO_DIP_SW2
AN13 GPIO_DIP_SW3
AN12 GPIO_DIP_SW4
AP12 GPIO_DIP_SW5
AL13 GPIO_DIP_SW6
AK13 GPIO_DIP_SW7

Power and Status LEDs

[Figure 2-1, callout 21]
Table 3-34 defines the power and status LEDs. For user controlled LEDs see
page 74.
Table 3-34: Power and Status LEDs
Reference
Schematic Net Name
Designator
DS1 FPGA_INIT_B
DS2 VCC12_SW
DS3 VCCAUX_PGOOD
VCC3V3_PGOOD
DS4
DS5 VCCINT_PGOOD
DS6 VADJ_FMC_PGOOD
DS7 VCC1V2_PGOOD
VCCBRAM_PGOOD
DS8
DS9 MGTAVTT_PGOOD
DS10 MGTAVCC_PGOOD
VCCPSINTFP_PGOOD
DS11
DS12 MGTRAVCC_PGOOD
DS13 MGTVCCAUX_PGOOD
DS14 VCCPSAUX_PGOOD
VCCPSPLL_PGOOD
DS15
DS16 VCCPSINTLP_PGOOD
DS17 DDR4_DIMM_VDDQ_PGOOD
MGTRAVTT_PGOOD
DS18
ZCU102 Evaluation Board User Guide
UG1182 (v1.2) March 20, 2017
I/O Standard
Name
LVCMOS33
LVCMOS33
LVCMOS33
LVCMOS33
LVCMOS33
LVCMOS33
LVCMOS33
LED Color
Green/Red
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
Green
www.xilinx.com
Chapter 3: Board Component Descriptions
Device
SW13.7
SW13.6
SW13.5
SW13.4
SW13.3
SW13.2
SW13.1
Description
Green: FPGA initialization was successful Red:
FPGA initialization is in progress
12VDC Power ON
VCCAUX 1.8VDC Power ON
VCC3V3 3.3VDC Power ON
VCCINT 0.85VDC Power ON
VADJ_FMC 1.8VDC (Nom.) Power ON
VCC1V2 1.2VDC Power ON
VCCBRAM 0.85VDC Power ON
MGTAVTT 1.2VDC Power ON
MGTAVCC 0.9VDC Power ON
VCCPSINTFP 0.85VDC Power ON
MGTRAVCC 0.85VDC Power ON
MGTVCCAUX 1.81VDC Power ON
VCCPSAUX 1.81VDC Power ON
VCCPSPLL 1.2VDC Power ON
VCCPSINTLP 0.85VDC Power ON
DDR4_DIMM_VDDQ 1.2VDC Power ON
MGTRAVTT 1.81VDC Power ON
Send Feedback
User I/O,
77
