IMMOBILIZER ANTENNA
Immobilizer antenna is installed in key set outer surface (it is
installed in the location of key hall illumination).(see the figure)
1 Immobilizer Antenna
2 Key
MAINTENANCE AND REPAIR
ON-VEHICLE SERVICE
IMMOBILIZER SYSTEM 9W-15
3 Transponder
