Building the Custom Chassis

Starting UltraNet
ConfigManager
Using the Custom
Chassis Wizard
The UltraNet Edge 3000 supports custom configuration which allows
you to select the type of WAN interface, client interface, and the
application type for the chassis.
This chapter provides the procedures for building a custom UltraNet
Edge 3000 chassis.
Use the following procedure to configure a customizable UltraNet
Edge 3000 chassis using the Custom Chassis Wizard.
The Custom Chassis Wizard is intended for use when configuring a
1x2 or 2x1 configuration type network. If you are configuring a 1x1 or
2x2 type solution, the UltraNet Edge 3000 Series Node menu contains
pre-designed selections for Ethernet and ATM 1x1 and 2x2
configurations, see Chapters 5, 6, and 7 for configuration examples.
The Wizard will step you through configuring each node you place
on the map.
Start the UltraNet ConfigManager (UCM) application from either the
icon on your desktop or the Start menu.
The Custom Chassis Wizard will start automatically if the Auto-Start
Custom Chassis Wizard for Edge3000 custom nodes box is checked.
This option is found on the Tool/Options menu, and is checked by
default.
