Modify Static Routes

E
Modify Static Routes

Add Static Routes

Delete Static Routes

UltraNet™ Edge Storage Router 3000 User Guide
E-4
This screen shows a defined default gateway and a host specific
static route for Node20. During the configuration process, the
default gateway fields are automatically updated when the
Ethernet Maintenance interface is configured via the "Initial
Config" step. The host specific static route fields are
automatically updated when the IP circuit is configured.
To modify the existing entries, highlight the data to be changed
and replace it with the new data.
If additional entries are required, click once in the Destination
field to enable the IP Static Routes information field, then add the
new data.
Click on the row selector at the left of the row for the IP Static
Route you want to delete. The row becomes highlighted to
indicate it has been selected. Then, press the Delete key. Repeat
these two steps for each route you want to delete.
