OC-3 ATM Specifications

OC-3 ATM Specifications

OC-3 ATM Cable and Connector Specifications

Table C-9
Cable Type
Multi-mode
(Short Reach)
Single-mode
(Long Reach)
UltraNet™ Edge Storage Router 3000 User Guide
C-8
The UltraNet Edge 3000 supports the
G.703, ITU-T G.704, ITU-T G.707, ITU I.432 and the ATM Forum
document af-phy-0062.000 for OC-3 ATM technology. Table C-9
provides the OC-3 ATM cable type specifications.
Note: Only multi-mode cables can be used with the
multi-mode transceivers.
Specification
Standard
Fiber/Cladding Diameter
Distance
Connector Type
Operational Wavelength
Data Rate
Receiver Sensitivity
Output Power
Maximum Input Power
Cable Attenuation (Max.)
Bandwidth (Min.)
Short Reach Transceiver
Standard
Fiber/Cladding Diameter
Transmitter output maximum power
Transmitter output minimum power
Forum UNI V3.1, ITU-T
ATM
OC-3 SONET/SDH STM-1
62.5/125 and 50/125 micron
50 micron = 850 meters
62.5 micron = 500 meters
Duplex LC
1300 nm
155 Mbps
-30 to -12 dBm
-19 to -14 dBm
-12 dBm
1.5dB @ 1300 nm
500 MHz/Km
2 Km
OC-3 SONET/SDH STM-1
9/125 micron
0 dBm
-5 dBm
