Configuring a 2x2 Ethernet Wide Area Network
6
McDATA UltraNet Edge 3000 User Guide
6-6
ConfigManager will use in each configuration. When
configuring F_port over an Ethernet WAN, select Fibre
Channel Switch (F_port).
— If you have previously added an UltraNet Edge 3000 node and
need to change the default Fibre Channel interface type, click
the Tools menu, then Options and select the appropriate
interface type from the drop-down list.
4. Move the cursor to another part of the map and click a second
time to create a second instance of the same type of node. Your
screen should look like the example below.
