Setting The Initial Configuration - McDATA ULTRANETTM EDGE STORAGE ROUTER 3000 User Manual

Configuring a 1x1 ATM Wide Area Network
7
Setting the Initial
Configuration
McDATA UltraNet Edge 3000 User Guide
7-6
If you configured an UltraNet Edge 3000 custom chassis (in Chapter
4), continue the configuration process with the "Setting the Initial
Configuration" procedure.
NOTE: When you are performing this part of the configuration, the PC
which has UltraNet ConfigManager installed on it, must be attached to the
same subnet as the UltraNet Edge Storage Router Ethernet maintenance
interface. If this is not possible, refer to the "Manual Configuration of the Initial
IP Settings" procedure, in Appendix H.
1. Right click on Node10 and select Set Initial Config from the
menu that appears.
The Initial Network Setup dialog box appears. The detected
UltraNet Edge Storage Router will appear in the section labeled
RECEIVED UltraNet Configuration Requests.
