11. Click on the drop-down arrow and select the appropriate IP
interface provider.
12. Click Next>.
NOTE: Use I/O port 3 for all 1x1 configurations.
When configuring a 2x2, use I/O port 3 to connect the first circuit and I/O
port 4 for the second circuit.
The IP Circuit Wizard Node20 Configure Interface dialog box
appears.
This dialog box enables you to configure IP interface properties
for Node20.
Configuring an F_Port Extension over an Ethernet WAN
Configuring a 2x2 Ethernet Wide Area Network
drop-down arrow
