RS-232 Cables with RJ-45 Connector

DB Adapters

This appendix lists the RS-232 cables, the DB adapters, and the
pinouts for the DB adapters available through McDATA. It also
contains cable and connector specifications for the Fibre Channel,
10/100 Ethernet, Gigabit Ethernet, and OC-3 ATM interfaces.
The RS-232 cable with RJ-45 connector is used to connect the UltraNet
Edge 3000 to a serial interface. Refer to Table C-1 for the lengths of the
RS-232 cable.
Table C-1

RS-232 Straight Through Cable with RJ-45 Connector Ends

Cable Length
10 feet
This section lists the Data Bus (DB) adapters available through
McDATA. If you need to build your own DB adapter, this section also
lists the pinouts for the DB adapters.
Cables, Connectors, and
C
Adapters
C-1
