McDATA Eclipse 2640 SAN Administration And Configuration Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
™
Eclipse
2640 SAN Router
Administration and Configuration
Manual
P/N 620-00203-020
REV A

Advertisement

Table of Contents
loading

Related Manuals for McDATA Eclipse 2640 SAN

Summary of Contents for McDATA Eclipse 2640 SAN

  • Page 1 ™ Eclipse 2640 SAN Router Administration and Configuration Manual P/N 620-00203-020 REV A...
  • Page 2 McDATA either owns or has the right to license the computer software programs described in this document. McDATA Corporation retains all rights, title and interest in the computer software programs.

  • Page 3: Table Of Contents

    Contents Chapter 1 Overview Introduction ..................1-2 SAN Router Features................1-4 Scalability Metrics..............1-5 SAN Router Layout ................1-6 Chapter 2 Configuring System Basics Configuring the SAN Router ............2-2 Setting the Management IP Address ........2-2 Setting Parameters Through the CLI ..........2-3 Using the Element Manager............2-5 Element Manager Overview ............2-6 Starting the Element Manager ..........2-7 Configuring the Management Port .........2-9...
  • Page 4 Contents Setting the SAN Routing Cluster ID........2-25 Procedure..................2-26 Configuring System Date and Time ........2-27 Configuring the Router Inband and Gateway Address ..2-28 Configuring SNMP..............2-30 Configuring mSNS ..............2-35 Configuring New Device Zoning..........2-35 Static Routes ..................2-36 Chapter 3 Configuring RADs and mSAN Connections Introduction..................3-2 mSANs ..................3-2 Port Configuration Tips............3-2...
  • Page 5 Contents Setting Advanced iSCSI Parameters ........5-9 Configuring iSCSI Devices............5-13 Adding iSCSI Devices Automatically ........5-13 Adding iSCSI Devices Manually .......... 5-14 iSCSI Devices Dialog Box Options and Data ...... 5-17 Zoning iSCSI Devices ..............5-19 Zoning without LUN Mapping/Masking ......5-19 Zoning with LUN Mapping/Masking ........
  • Page 6 Contents Backup..................7-12 Restore..................7-13 Retrieving and Clearing the System Log ........7-14 Chapter 8 Troubleshooting Element Manager Troubleshooting ..........8-2 SAN Router Troubleshooting ............8-5 Eclipse™ 2640 SAN Router Administration and Configuration Manual...
  • Page 7 Figures Eclipse 2640 SAN Router ................1-3 Eclipse 2640 LEDs, Ports, and Connectors ..........1-6 Element Manager Login Dialog Box ............2-8 Element Manager window ................2-9 Management Port Configuration Dialog Box ......... 2-10 Get Write Permission Dialog box ............. 2-11 Internal and External IP Addresses ............
  • Page 8 Figures iFCP Setup Dialog Box ................4-14 Remote Connections Dialog Box .............. 4-15 Add Remote Connection Dialog Box ............4-18 Edit Remote Connection Dialog Box ............4-20 iFCP Port Redundancy Configuration Dialog Box ........ 4-22 4-10 MAN/WAN Links ..................4-24 4-11 Automatic Communication ...............
  • Page 9 Figures 6-10 Fan Tool Tip ....................6-10 6-11 Message Log ....................6-10 6-12 Poll Interval Dialog Box ................6-12 6-13 Network Utilities Dialog Box ..............6-13 6-14 GE Port Statistics Dialog Box ..............6-15 6-15 FC Port Statistics Dialog Box ..............6-18 6-16 FC Device Properties Screen ..............
  • Page 10 Figures Eclipse™ 2640 SAN Router Administration and Configuration Manual...
  • Page 11 Tables Eclipse 2640 SAN Router Features ............. 1-4 Element Manager Workstation Requirements ......... 2-5 Element Manager Software Functions ............2-6 Key Board Shortcuts ................... 2-11 Generic SNMP MIB-II traps, from RFC 1213 .......... 2-31 RMON Traps, from RFC 1757, Enterprise 1.3.6.1.2.1.16 ....... 2-31 Fibre Alliance traps, enterprise 1.3.6.1.3.94 ..........
  • Page 12 Tables Element Manager Problems and Solutions ..........8-2 SAN Router Problems and Solutions ............8-5 Eclipse™ 2640 SAN Router Administration and Configuration Manual...
  • Page 13 Preface This manual provides the information required to configure and use the Eclipse 2640 SAN Router in an Ethernet/IP or Fibre Channel (FC) data network. Who Should Use this Manual The manual is designed for IT professionals, including experienced Data Networking Administrators and System Architects.
  • Page 14 • E/OSi Command Line Interface (CLI) User Manual (620-000207-050). • SANvergence Manager User Manual (620-000189). • Eclipse 2640 SAN Router Installation and Service Manual (620-000202). • E/OSi SNMP Support Manual (620-000228) • McDATA Products in a SAN Environment Planning Manual (620-000124) •...
  • Page 15 McDATA’s “Best in Class” Solution Center provides a single point of contact for customers seeking help. The Solution Center will research, explore, and resolve inquires or service requests regarding McDATA products and services.
  • Page 16 NOTE: Customers who purchased the hardware product from a company other than McDATA should contact that company’s service representative for technical support. Forwarding Publication Comments We sincerely appreciate any comments about this publication. Did you find this manual easy or difficult to use? Did it lack necessary...
  • Page 17 To order a paper copy of this manual, submit a purchase order as Ordering Publications described in Ordering McDATA Documentation Instructions, which is found on McDATA’s web site at the following location: www.mcdata.com/downloads/tpub/other/customer_ordering_inst ructions.pdf. To obtain documentation CD-ROMs, contact your sales representative.
  • Page 18 Eclipse™ 2640 SAN Router Administration and Configuration Manual xviii...

  • Page 19: Overview

    Overview This chapter provides an introduction to the Eclipse 2640 SAN Router. Use the following links to move through this chapter. Section Page Introduction SAN Router Features SAN Router Layout Overview...

  • Page 20: Introduction

    Introduction Introduction The Eclipse 2640 SAN Router (referred to as SAN Router in this manual) supports iSCSI, iFCP, and R_Port for trunking to both Internet Protocol (IP) backbones and legacy Fibre Channel (FC) fabrics. The SAN Routers connect to a wide range of end systems, including Fibre Channel, NAS, and iSCSI initiators and targets.

  • Page 21: Eclipse 2640 San Router

    Introduction Eclipse 2640 SAN Router Figure 1-1 Two management ports are located on the front of the SAN Router. An RS-232 serial port can connect to a VT100 or terminal emulator for access to the Command Line Interface (CLI), and an RJ45 port can connect to the LAN for out-of-band management through the SAN Router Element Manager and SANvergence Manager.

  • Page 22: San Router Features

    SAN Router Features SAN Router Features The Eclipse 2640 SAN Router features are summarized in the following table. Table 1-1 Eclipse 2640 SAN Router Features Feature Description Intelligent Ports The SAN Router supports two types of ports - standard ports and intelligent ports.

  • Page 23: Scalability Metrics

    SAN Router Features Table 1-1 Eclipse 2640 SAN Router Features (Continued) Feature Description Real-time and historical The Element Manager and Log Viewer can be used to look at system logs current system log messages from the connected SAN Router. Compression...

  • Page 24: San Router Layout

    SAN Router Layout SAN Router Layout The SAN Router front panel (Figure 1-2 on page 1-6) provides an Ethernet LAN connector (10/100), small form-factor pluggable (SFP) connectors port status LEDs, and a green system (SYS) LED. The panel also provides a 9-pin DSUB maintenance port (CONSOLE) for connection to a local terminal or remote terminal.

  • Page 25: Configuring System Basics

    Configuring System Basics This chapter provides steps for configuring the SAN Router’s basic functions before performing specific configuration for various network connections. Use the following links to move through the chapter. Section Page Configuring the SAN Router Setting Parameters Through the CLI Using the Element Manager Tips on using the Element Manager 2-11...

  • Page 26: Configuring The San Router

    Configuring the SAN Router Configuring the SAN Router You can configure the SAN Router using any of the three options as follows: • Command Line Interface (CLI). For this method a VT100 terminal or PC with terminal emulation software running must be connected to the RS-232 serial port on the SAN Router.

  • Page 27: Setting Parameters Through The Cli

    10.xx.yy.zz where, xx is the cabinet number (1, 2, 3, etc.) yy is the product type identifier (16 for the Eclipse 2640 SAN Router) zz is the position in the rack, bottom to top (1, 2, 3, etc.)
  • Page 28 Setting Parameters Through the CLI Parameter Setting Bits per second 9600 Data bits Parity bits None Stop bits Flow Control None 3. Power up the terminal. Press the Enter key to display the CLI prompt. 4. Type modify at the Access Mode prompt. This is case-sensitive. Read is for read-only;...

  • Page 29: Using The Element Manager

    Using the Element Manager 9. Reset the system using the following command: reset system The management IP address is now set and ready for normal operation. 10. If you require a terminal connection to the 10/100 port for out-of-band management, connect the standard RJ45 Cat 5 Ethernet cable from the LAN to the management port.

  • Page 30: Element Manager Overview

    Using the Element Manager Table 2-1 Element Manager Workstation Requirements(Continued) IBM Compatible Intel Pentium Class PC, 400 Sun Ultra 5 or better; 300 MHz or above, with MHz or above with mouse, 32-bit mouse Internet Explorer 6.0 or higher or Netscape 6.22 Mozilla 1.4 Web Browser or higher...

  • Page 31: Starting The Element Manager

    Using the Element Manager Table 2-2 Element Manager Software Functions(Continued) Function Configuration Options System Configuration Operations (Configuration menu) Properties Inband Address SNMP Communities/Hosts SNMP Traps Date/Time New Device Zoning Port Configuration Management, FC/Ethernet (Fibre Channel, Ethernet and (Configuration menu) TCP Ports with iSCSI and/or iFCP) Advanced FC Port (E_D_TOV and R_A_TOV timeout values) Static Routing (Configuration...

  • Page 32: Element Manager Login Dialog Box

    Using the Element Manager 1. In the address field of your browser, enter the management IP address or DNS hostname of the target SAN Router (for example: 192.168.2.16), in the Address field. Some browsers may require “http://” before a hostname. The Element Manager login dialog box appears.

  • Page 33: Configuring The Management Port

    Using the Element Manager Element Manager window Figure 2-2 You are now logged in and ready to use Element Manager. If SANvergence Manager software is installed, click Element Manager button on the SANvergence screen. Configuring the Management Port To configure the out-of-band management port, follow these instructions: 1.

  • Page 34: Management Port Configuration Dialog Box

    Using the Element Manager Management Port Configuration Dialog Box Figure 2-3 2. Enter the IP address and subnet mask address for the management port. 3. Click Edit Gateway to add the IP address of the gateway router to the static route table if any of your management stations are on a different subnet than the one you are specifying for the management port.

  • Page 35: Tips On Using The Element Manager

    Tips on using the Element Manager Tips on using the Element Manager An HTML-based help system is available with the Element Manager. Getting Help You can search for text on a topic that interests you or browse help topics sequentially. To view help, choose Index from the Help menu. You can also click the Help button or press F1 in a dialog box to view help customized for that dialog box.

  • Page 36: Granting Clipboard Access For Copy And Paste

    Tips on using the Element Manager CAUTION Only one user at a time should be allowed to login with read and write privileges so as not to write over each other’s changes. Granting Clipboard Access for Copy and Paste Element Manager is an unsigned Java applet.

  • Page 37: Using With Third-Party Browser Extensions

    Tips on using the Element Manager NOTE: Alternatively, for either operating system, you may instead edit the.java.policy file (note different name, with period in front) in the user's home directory. For Windows XP, the directory would be C:\Documents and Settings\<login-name>. To grant clipboard access, follow these instructions: 1.

  • Page 38: Using Configuration Dialog Boxes

    Tips on using the Element Manager 1. Select Internet Options under the Tools menu in Microsoft® Internet Explorer. 2. Click the Advanced tab. 3. Under Browsing, disable Enable third-party browser extensions, if enabled. 4. Restart your computer. The Windows XP Service Pack 2 provides the ability to individually enable or disable an extension (now called an add-on) in Internet Explorer without entirely disabling third-party extension support.

  • Page 39: Configuring Ip Addresses

    Configuring IP Addresses Configuring IP Addresses SAN Routers use the iFCP and iSCSI protocols, which use IP addresses for all routing and forwarding of storage traffic. Using the iFCP/iSCSI protocol, all Fibre Channel addresses are mapped to one or more IP addresses. You must configure two IP addresses with SAN Routers: the external iFCP/iSCSI network and the IP network.

  • Page 40: Internal And External Ip Addresses

    Configuring IP Addresses Figure 2-5 Internal and External IP Addresses A SAN Router has iFCP/iSCSI ports that are connected to the external IP network, and one or more ports that are connected to the internal IP network. Each TCP port connects to each network (both the internal and external networks) as an independent device.

  • Page 41: The Router Inband Ip Address

    Configuring IP Addresses Figure 2-5 shows the role and position of each IP address relative to the internal and external IP networks. The Router Inband IP Address The router inband IP address is used for the internal delivery of storage traffic. To configure the SAN Router inband address, use Configuration>System>Inband Address in the Element Manager.

  • Page 42: The Next Hop Gateway Ip Address

    Configuring IP Addresses Figure 2-7 FC/Ethernet Port Configuration Dialog Box The Next Hop Gateway IP Address The iFCP/iSCSI ports interact with the external IP network as if they were independent IP hosts. Each iFCP/iSCSI port needs a gateway address of an external router that can forward the storage traffic to the remote iFCP/iSCSI port.

  • Page 43: The Internal Ip Address

    Configuring IP Addresses The Internal IP Address Storage traffic that is to be transported through the external network by iFCP or iSCSI must first be delivered to the iFCP/iSCSI port that will perform the iFCP/iSCSI encapsulation. The internal IP address is used by the iFCP/iSCSI port to receive this storage traffic from the internal network.

  • Page 44: Guidelines When Working With Firewalls

    Configuring IP Addresses Figure 2-8 FC/Ethernet Port Configuration Dialog Box Guidelines When Working with Firewalls The iFCP and iSCSI protocols use TCP for transmission. TCP provides several benefits such as: • Retransmission of any packets dropped by the network. • Guaranteed in-order delivery.
  • Page 45 Configuring IP Addresses connection is established are the TCP segments allowed to be transmitted from the sender to the receiver. A firewall can be used to block the establishment of TCP for some applications while permitting other applications to transmit data. To accomplish this, firewalls frequently use a combination of TCP port numbers and IP addresses.
  • Page 46 Configuring IP Addresses • Ping operation results (37010) The following datapath ports must be open if you want to manage across a firewall using SANvergence Manager: • SNMP Protocol (161) • SNMP Traps (162) Eclipse™ 2640 SAN Router Administration and Configuration Manual 2-22...

  • Page 47: Configuring System Operations

    Configuring System Operations Configuring System Operations Configuring the system operations of a SAN Router involves the following steps: 1. Configuring the system properties 2. Setting the system date and time 3. Setting the SAN Routing Cluster ID 4. Configuring SNMP 5.

  • Page 48: System Properties Dialog Box

    Configuring System Operations System Properties Dialog Box Figure 2-9 2. Login banner lets you customize the banner which gets displayed in the HTML starting page above the login dialog box. The banner may be up to 25 lines long with up to 80 characters per line.

  • Page 49: Setting The San Routing Cluster Id

    Configuring System Operations Login Banner Figure 2-10 3. Click OK or Apply. 4. Choose Save Configuration from the File tab to permanently save your changes to the runtime configuration. This saves the currently running configuration to flash memory. Setting the SAN Routing Cluster ID The R_Port SAN Routing Cluster ID is used by the SAN Router R_Ports to register a unique virtual node WWN to the connected fabrics.

  • Page 50: Procedure

    Configuring System Operations The values set take effect only after the SAN Router R_Ports are disabled and enabled (re-initialized). NOTE: Changing the cluster ID changes the registered virtual switch node WWN. This may require the management applications to re-discover the SAN Router.

  • Page 51: Configuring System Date And Time

    Configuring System Operations Configuring System Date and Time To configure the system date and time from the SAN Router’s clock and configure Simple Network Time Protocol (SNTP), follow these instructions: 1. Select Configuration>System>Date/Time to display the Date/Time dialog box. The Date/Time dialog box displays the current date and time from the SAN Router’s clock as shown in Figure 2-12.

  • Page 52: Configuring The Router Inband And Gateway Address

    Configuring System Operations SAN Router Time Zone - Select a time zone from the drop-down list. Daylight Savings Time - Select On or Off from the drop-down list if daylight savings time pertains to your time zone. The SAN Router does not automatically change this setting when daylight savings time begins or ends.

  • Page 53: Inband Address Configuration Dialog Box

    Configuring System Operations Configuring the Router Inband Address To configure the SAN Router’s internal “router inband” address through the Element Manager, follow these instructions: 1. Select Configuration>System>Inband Address to display the Inband Address Configuration dialog box (Figure 2-13). Inband Address Configuration Dialog Box Figure 2-13 2.

  • Page 54: Configuring Snmp

    Configuring System Operations Configuring SNMP To configure the SNMP communities and hosts, follow these instructions: 1. Select Configuration>System>SNMP Communities/Hosts to display the SNMP Communities/Hosts dialog box (Figure 2-14 page 2-30). SNMP Communities/Hosts Dialog Box Figure 2-14 2. Type the read-only password and read-modify password (community strings) for the SAN Router.

  • Page 55: Generic Snmp Mib-Ii Traps, From Rfc 1213

    Configuring System Operations 5. Choose Save Configuration from the File tab to permanently save your changes to the runtime configuration. This saves the currently running configuration to flash memory. Configuring System SNMP Traps The SAN Router sends SNMP traps to notify the management station of certain events.

  • Page 56: Mcdata Eclipse Traps, Enterprise 1.3.6.1.4.1.4369.3

    A port status has changed. Sent when a port is enabled or disabled, or the Info Change link goes up or down. (if port up) Critical if port disabled or down. McDATA Eclipse traps, enterprise 1.3.6.1.4.1.4369.3 Table 2-7 Trap Name Description Severity SNS Server The SAN Router has become the primary SNS server. Info Firmware Loaded A new firmware image has completed a TFTP download to flash memory.
  • Page 57 Configuring System Operations Table 2-7 McDATA Eclipse traps, enterprise 1.3.6.1.4.1.4369.3 (Continued) Trap Name Description Severity iFCP Backup Sent when a backup iFCP port begins to activate its backup connections. Critical Activated This may be caused by the primary port becoming unreachable or the primary port informing the backup port that the primary link has gone down.

  • Page 58: Snmp Traps Dialog Box

    Configuring System Operations Figure 2-15 SNMP Traps Dialog Box 2. Configure up to eight (8) trap receivers, each with a severity filter. Use the severity level drop down list to specify the traps with specific severity levels that should be sent to each address. Figure 2-16 SNMP Traps Filter Pull Down Menu 3.

  • Page 59: Configuring Msns

    Configuring System Operations Configuring mSNS The SAN Router’s metro storage name server (mSNS) stores the inventory of hosts and storage devices in the mSAN as well as zoning information, to specify which hosts can use which storage devices. SAN Router discovers the Inventory information automatically. You can view inventory information for locally attached devices by selecting Storage Name Server from the Statistics/Info tab.

  • Page 60: Static Routes

    Static Routes 3. Click Place in a default router zone (zone 1) to place all new devices in the default zone (zone 1) where they can communicate with each other. 4. Click OK. 5. Choose Save Configuration from the File tab to permanently save your changes to the runtime configuration.

  • Page 61: Configuring System Basics

    Static Routes If the SAN Router is responding to an IP packet that originated from, for example, the SNMP management station on 10.1.4.2, then it needs to be told to route the response over the management port to the SAN Router 10.1.3.1.

  • Page 62: Static Routing Configuration Dialog Box

    Static Routes Static Routing Configuration Dialog Box Figure 2-19 NOTE: Use the lower portion of this dialog box to create a permanent static route to the subnet where your management workstation(s) reside. For more information, refer to Configuring the Management Port page 2-9.

  • Page 63: Add Static Route Dialog Box

    Static Routes status is Added Not Applied and the row is green. If you select an entry to be removed, the entry status is Removed Not Applied and the row is red. Important Notes for Static Routes If the SAN Router is to be managed from a single external subnet, follow the directions under Static Routes.

  • Page 64: Static Routing Parameters

    Static Routes Static Routing Parameters Table 2-8 Item Meaning Static Route Destination Defines the destination subnetwork of the traffic to be routed by the static route entry. Static Route Mask Coupled with the Static Route Destination, the Static Route Mask defines the destination subnetwork of the traffic to be routed by the static route entry.

  • Page 65: Chapter 3 Configuring Rads And Msan Connections

    Configuring RADs and mSAN Connections This chapter provides steps for configuring the SAN Router and its Fibre Channel ports for attaching directly to Fibre Channel devices, such as servers and storage. Use the following links to move through the chapter. Section Page Introduction...

  • Page 66: Introduction

    MAN services, etc. Eclipse 2640 SAN routing done within an mSAN is referred to as mSAN Routing or SAN Routing within the data center. An mSAN...
  • Page 67 Introduction • To directly attach a SAN Router to an Fibre Channel switch, configure the ports 1-12 as a R_Ports. For details, refer to on page 3-6. Configuring R_Ports for mSANs • Configuring and Managing Zones in R_Port Connected Networks - SANvergence Manager Version 4.7 or higher is required to manage zones for R_Port connected networks.

  • Page 68: Configuring The Fc Ports For Router-Attached Devices

    Configuring the FC Ports for Router-Attached Devices Configuring the FC Ports for Router-Attached Devices This section describes how to configure the Fibre Channel ports on the SAN Router as R_Ports for attaching directly to an Fibre Channel device. To configure R_Ports for attaching to an Fibre Channel switch (mSAN), refer to on page 3-6.
  • Page 69 Configuring the FC Ports for Router-Attached Devices 3. Type a label for this port in the Port Name field. This label is displayed in the port tooltip, statistics, and other dialog boxes. 4. Port Speed: Click the Port Speed list and select either 1 Gigabit, 2 Gigabit, or Auto.

  • Page 70: Configuring R_Ports For Msans

    Configuring R_Ports for mSANs Configuring R_Ports for mSANs The following procedure describes how to configure an Fibre Channel port as an R_Port to attach Fibre Channel devices and mSANs. 1. Perform steps 1 through 7 under Configuring the FC Ports for on page 3-4.

  • Page 71: Fc/Ethernet Port Configuration Dialog Box

    Configuring R_Ports for mSANs FC/Ethernet Port Configuration Dialog Box Figure 3-2 Table 3-1 on page 3-8 describes the current R_Port parameters that may appear. Configuring RADs and mSAN Connections...

  • Page 72: R_Port Parameters

    • For Brocade mode: 1 to 239. 126 and 127 are reserved. • For Open Fabric1.0 mode: 1 to 29. 30 and 31 are reserved. • For McDATA Fabric 1.0 mode: 11 to 29. 30 and 31 are reserved. Use SANvergence Manager or the CLI to set this parameter. To avoid...
  • Page 73 3. To configure the R_Port using different parameters that are displayed, use SANvergence Manager. Refer to instructions for configuring R_Port parameters in Chapter 4 of the McDATA SANvergence Manager User Manual (620-000189). 4. Note that the FC port timeouts, E_D_TOV and R_A_TOV, must be configured the same on the SAN Router and all Fibre Channel switches in an attached fabric.

  • Page 74: Configuring Advanced Fc Port Parameters

    Configuring Advanced FC Port Parameters Configuring Advanced FC Port Parameters To configure FC port timeouts, follow these instructions: 1. Select Configuration>Port >Advanced FC Port to display the Advanced FC Port Configuration dialog box. Figure 3-3 Advanced FC Port Configuration Dialog Box 2.

  • Page 75: Example Configuration And Procedures

    Example Configuration and Procedures Example Configuration and Procedures This section provides a specific example of procedures to configure a SAN Router for a RAD, as well as an mSAN consisting of an Fibre Channel switch and attached storage (Figure 3-4). Figure 3-4 Connecting to Fabric and FC Device The configuration in...
  • Page 76 Example Configuration and Procedures 3. Follow steps under Configuring the FC Ports for Router-Attached on page 3-4 to configure port 3 for connecting to the FC Devices server. Make sure to select FC-Auto under FC Port Parameters on the FC/Ethernet Port Configuration dialog box. 4.

  • Page 77: Configuration Notes For All R_Ports On The Same Fabric

    World Wide Node Name (WWNN)-based zoning is not supported. In order to maintain interoperability between the McDATA fabric and third party fabrics, ensure that “soft” zoning on the fabric side is done using World Wide Port Names of devices instead of World Wide Node Names of devices.

  • Page 78: R_Port Compatibility

    R_port Compatibility R_port Compatibility The following R_Port compatibility table shows support for attaching Fibre Channel switches to the Eclipse 2640 SAN Router. The Fibre Channel switches must be operating in either McDATA Fabric 1.0 or Open Fabric 1.0 interoperating mode.

  • Page 79: Chapter 4 Configuring Isan Connections

    Configuring iSAN Connections This chapter provides detailed steps for configuring the SAN Router ports for iFCP and setting up iFCP connections. Use the following links to move through the chapter. Section Page Introduction Configuring TCP Ports for iFCP 4-14 Configuring iFCP Connections 4-22 Configuring a Backup iFCP Connection 4-24...

  • Page 80: Introduction

    Introduction Introduction An iSAN (internetworked storage area network) is a collection of one or more fabrics interconnected using one or more SAN Routers, where at least one fabric is in a distant location outside the metro area. An iSAN is characterized by high latency and low bandwidth inter-switch links (T1, T3, OC3, etc.) such as those found in wide area networks.

  • Page 81: Isan Configuration Example

    Introduction iSAN Configuration Example Figure 4-1 Chapter 3 provides instructions for configuring the SAN Router to create an mSAN by attaching fabrics to the SAN Router R_Ports. Chapter 4 provides steps for interconnecting mSANs with remote mSANs over a WAN. Connections to the network are made through those SAN Router’s TCP ports available for configuring FC Protocol (iFCP) connections.

  • Page 82: Configuring Tcp Ports For Ifcp

    Configuring TCP Ports for iFCP Configuring TCP Ports for iFCP This section describes how to configure the TCP ports (port numbers 13-16 on the Eclipse 2640 SAN Router) for iFCP connections. This involves the following procedures: • Setting the general port parameters •...

  • Page 83: Fc/Ethernet Port Configuration Dialog Box

    Configuring TCP Ports for iFCP FC/Ethernet Port Configuration Dialog Box Figure 4-2 2. Select a port. The screen is refreshed to show the operational state. 3. Type a label for this port in the Port Name field. 4. Set the port speed under the Port Speed list, if needed and select the Enable Port checkbox.

  • Page 84: Setting The Advanced Tcp Parameters

    Configuring TCP Ports for iFCP 6. Select the Flash LED option to blink the port LED. You can use this option to locate the physical port in a rack of SAN Routers. Setting the Advanced TCP Parameters The SAN Router provides options to optimize the TCP port behavior through a set of advanced parameters.
  • Page 85 Configuring TCP Ports for iFCP Manual Reset: You may not want the auto-reset option to be on when you are troubleshooting unrecoverable errors. In this case, you can do a manual reset by clicking Reset Port in the FC/Ethernet Port Configuration dialog box. 2.
  • Page 86 Configuring TCP Ports for iFCP 1. Select Smaller CWND Reduction in Fast Recovery to improve the performance of the SAN Router when packet losses occur due to reordering or noise rather than congestion. When enabled, the SAN Router responds more slowly to congestion events because the send congestion window (CWND) is reduced to 7/8 of its previous value as compared to 1/2 in standard TCP.

  • Page 87: Setting The Ifcp Parameters

    Configuring TCP Ports for iFCP 6. Specify the number of ACKs that trigger Fast Retransmit or Fast Recovery using the Threshold field. Valid values are between 8 to 128, with a default of 8. Larger values reduce retransmissions by causing the SAN Router to wait longer for retransmitted packets to arrive.

  • Page 88: Advanced Tcp Configuration Ifcp Parameter

    Configuring TCP Ports for iFCP Advanced TCP Configuration iFCP Parameter Figure 4-4 1. Select the compression behavior for the TCP/IP port using the Compression Level combo box. Compression is an optional software feature; the Compression Level field is disabled if compression is not included in your software version.
  • Page 89 Configuring TCP Ports for iFCP • HW - All transmitted data is compressed using the hardware feature in the SAN router. This is the recommended setting if the remote destination also supports HW compression. • SW - All transmitted data is compressed, using the SAN router’s CPU.
  • Page 90 Configuring TCP Ports for iFCP Select Hardware Compression from the Compression Level drop-down list. This has the lowest compression ratio, but it can run at link rate. 3. Select Selective ACKnowledgement (SACK) to acknowledge non-contiguous sequence numbers. This reduces the amount of retransmitted data when packets are lost.
  • Page 91 Configuring TCP Ports for iFCP Router without a XFER_RDY from the target device. Specify the maximum amount of buffered data, in kilobytes, in the text field. The memory limit is a single pool for all Fabric Channel login sessions. • Selecting the Transmit Buffer Management option allows the user to manage the amount of Fabric Channel receive buffers that an iFCP port has for receiving the Fabric Channel frames forwarding from Fabric.

  • Page 92: Configuring Ifcp Connections

    Configuring iFCP Connections Configuring iFCP Connections To configure an iFCP connection, configure a TCP port (13-16) as iFCP, as described in on page 4-4. A Configuring TCP Ports for iFCP pair of SAN Routers connects two mSANs. Each mSAN is identified by a unique mSAN ID and each has its own mSNS.

  • Page 93: Remote Connections Dialog Box

    Configuring iFCP Connections • Set the local mSAN ID when the SAN Router is installed. The default value is zero (0). The local mSAN ID is a number between 0 and 4,294,967,295 that uniquely identifies the local mSAN. NOTE: The SAN Router at each end of the iFCP link (and thus the mSANs at each end) must have different mSAN IDs.

  • Page 94: Read-Only Remote Connections Parameters

    Configuring iFCP Connections Read-Only Remote Connections Parameters Table 4-1 Column Description Connection Indicates whether the connection is primary (manually configured on this SAN Router) or backup (automatically copied from this SAN Router or another SAN Router so the local SAN Router can back up the connection).
  • Page 95 Configuring iFCP Connections NOTE: Backup connections (identified by Backup in the Connection column) cannot be selected, even when the backup connection is active. Backup connections cannot be edited or removed. These connections inherit their settings from the corresponding primary connection. CAUTION When exporting zones across iFCP, make sure the zone members are device WWNs and not fabric ports, as fabric port zones are not...

  • Page 96: Add Remote Connection Dialog Box

    Configuring iFCP Connections Figure 4-7 Add Remote Connection Dialog Box Use this dialog box to add new remote iFCP connections or edit parameters for existing connections. You can modify information in this dialog box as described in Table 4-2. Eclipse™ 2640 SAN Router Administration and Configuration Manual 4-18...

  • Page 97: Remote Connections Parameters

    Configuring iFCP Connections Remote Connections Parameters Table 4-2 Setting Description Connection Description Enter up to 32 characters of description to help remember the purpose of this connection. Local SAN Router Port Select the port on the local SAN Router from the drop-down list.

  • Page 98: Edit Remote Connection Dialog Box

    Configuring iFCP Connections Figure 4-8 Edit Remote Connection Dialog Box NOTE: To select a range of connections, select the first, then hold down the Shift key while selecting the last connection. To select a set of connections, hold down the Ctrl key while clicking on each connection. 3.
  • Page 99 Configuring iFCP Connections • A connection with a status of Down is enabled but inactive. The SAN Router periodically attempts to restore a failed connection. If you wish to initiate a reconnection attempt (for example, after you’ve corrected the cause of the connection failure), select the connection and click the Restart button.

  • Page 100: Configuring A Backup Ifcp Connection

    Configuring a Backup iFCP Connection Configuring a Backup iFCP Connection You can configure redundant fail-over for the iFCP connection so that one iFCP port backs up another iFCP port on the same SAN Router. Redundant ports must be configured symmetrically; for example, each port must back up the other.
  • Page 101 Configuring a Backup iFCP Connection 5. Set the Timeout for backup activation to between 5 and 60 seconds (default is 5 seconds). If the backup port cannot reach the primary port through the local SAN for this period of time, the backup port assumes that the primary port has failed and activates the redundant connection.

  • Page 102: Example Configurations And Procedures

    Example Configurations and Procedures Example Configurations and Procedures This section provides procedures to configure the SAN Router for connecting remote SANs through iFCP. This section assumes that you have SANvergence Manager software installed. Figure 4-10 illustrates two SAN Routers connecting two FC disks across a TCP/IP metropolitan area network (MAN) or wide area network (WAN).

  • Page 103: Configuring Ports And Connections

    Example Configurations and Procedures • If the WAN link is severed, separate mSNS servers allow continued undisturbed communication between initiators and targets within the local and remote sites. • When the WAN link is reconnected, communication between the local and remote devices is automatic and no fabric resets are necessary to reconverge the network.
  • Page 104 Example Configurations and Procedures 2. Enter the default Modify password (private) in the field provided and click OK. 3. When the Element Manager window appears, select Configuration>System>Inband Address to change the SAN Router’s inband address parameters. • Set the inband address to 192.168.20.131. When you change the Inband IP address, you must reset the SAN Router before you can configure the iFCP port.

  • Page 105: Fc/Ethernet Port Configuration Dialog Box

    Example Configurations and Procedures When you change the Inband IP address, you must reset the SAN Router before you can configure the iFCP port. 12. Select Configuration>Ports>FC/Ethernet when Element Manager displays the FC/Ethernet Port Configuration dialog box (Figure 4-12 on page 4-27). FC/Ethernet Port Configuration Dialog Box Figure 4-12 •...

  • Page 106: Setting Up Remote And Exported Connections And Zones

    Example Configurations and Procedures • Select iFCP under iSCSI/iFCP Parameters and enter the following information: • Port IP- 192.168.27.130 • Subnet Mask- 255.255.255.0 • Next Hop Gateway Address: 0.0.0.0 • Internal address: 192.168.17.131 • Select OK. 13. Select Configuration>iFCP>Setup to display the iFCP Setup dialog box, and enter 130 for the Local mSAN ID.
  • Page 107 Example Configurations and Procedures • Create a New Zone and name it “Remote Zone” (take note of the Zone ID for the zone). • Right-click the HBA Port WWN located off the attached port under the right column and left click Add with the Remote Zone highlighted on the left.
  • Page 108 Example Configurations and Procedures Eclipse™ 2640 SAN Router Administration and Configuration Manual 4-30...

  • Page 109: Chapter 5 Configuring Iscsi Connections

    Configuring iSCSI Connections This chapter provides procedures to configure the SAN Router to support line-rate communication between iSCSI initiators and Fibre Channel targets. Use the following links to move through the chapter. Section Page Introduction Configuring iSCSI Ports 5-13 Configuring iSCSI Devices 5-19 Zoning iSCSI Devices 5-25...

  • Page 110: Introduction

    Introduction Introduction SAN Routers support true gigabit wire-speed iSCSI-FC gateway functionality, which means they can translate iSCSI traffic to Fibre Channel traffic and vice versa. Using SAN Routers, iSCSI initiators can access FC storage devices as shown in Figure 5-1. The initiators and targets (FC or iSCSI) can be either directly connected to the SAN Router or connected across an FC or IP network as shown.
  • Page 111 Introduction Example Configuration Figure 5-2 The server in Figure 5-2 can either be directly connected to the SAN Router or indirectly connected via an intermediate IP network. For a direct-attached configuration, the server must be physically connected to the iSCSI-capable ports (13-16) on the SAN Router. When connected via an intermediate IP network, the server must have IP connectivity to one of the TCP ports on the SAN Router.

  • Page 112: Iscsi Configuration Procedures

    Configuring iSCSI Ports iSCSI Configuration Procedures To configure iSCSI communication with fabrics, follow these steps: 1. Configure the TCP ports for iSCSI. Follow the procedures under on page 5-4. Configuring iSCSI Ports 2. Configure the iSCSI access control list. Follow procedures under on page 5-13.

  • Page 113: Fc/Ethernet Port Configuration Dialog Box

    Configuring iSCSI Ports FC/Ethernet Port Configuration Dialog Box Figure 5-3 2. Select a port. The screen is refreshed to show the operational state. 3. Type a label for this port in the Port Name field. 4. Set the port speed under the Port Speed list, if needed. Select the Enable Port checkbox.

  • Page 114: Setting The Advanced Tcp Parameters

    Configuring iSCSI Ports 6. Select the Flash LED option to blink the port LED. You can use this option to locate the physical port in a rack of SAN Routers. 7. Select the type of the port as iSCSI. Setting the Advanced TCP Parameters The SAN Router provides options to optimize the TCP port behavior for storage traffic in a dedicated enterprise network through a set of advanced parameters.
  • Page 115 Configuring iSCSI Ports • Select Auto-reset port on severe errors especially when the port is a part of a mission-critical configuration. Manual Reset: You may not want the auto-reset option to be on when you are troubleshooting unrecoverable errors. In this case, you can do a manual reset by clicking Reset Port in the FC/Ethernet Port Configuration dialog box.
  • Page 116 Configuring iSCSI Ports 1. Select Smaller CWND Reduction in Fast Recovery to improve the performance of the SAN Router when packet losses occur due to reordering or noise rather than congestion. When enabled, the SAN Router responds more slowly to congestion events because the send congestion window (CWND) is reduced to 7/8 of its previous value as compared to 1/2 in standard TCP.

  • Page 117: Setting The Iscsi Parameters

    Configuring iSCSI Ports NOTE: Enabling reorder resistance could slightly delay recovery from dropped packets in short data messages. Specify the number of ACKs that trigger Fast Retransmit or Fast Recovery using the Threshold field. Valid values are between 8 to 128, with a default of 8.

  • Page 118: Advanced Tcp Configuration

    Configuring iSCSI Ports 1. Select the iSCSI tab from the Advanced TCP Configuration dialog box (refer to Figure 5-5) to specify the iSCSI parameters: Figure 5-5 Advanced TCP Configuration iSCSI Parameters • Selective ACKnowledgement - (SACK) allows acknowledgement of non-contiguous sequence numbers to reduce the amount of retransmitted data when packets are lost.
  • Page 119 Configuring iSCSI Ports NOTE: Digest and large PDU cannot both be enabled at the same time. • Initial R2T - (request to transfer). This skips the requirement for an initial R2T in unidirectional and the output part of bidirectional commands. •...
  • Page 120 Configuring iSCSI Ports • Login Retry timeout (in seconds) - This determines when the initiator can attempt to log into the SAN Router after a device is unzoned or disconnected. — Always Retry - iSCSI initiators are not notified that the device is no longer available.

  • Page 121: Configuring Iscsi Devices

    Configuring iSCSI Devices Configuring iSCSI Devices There are two ways to configure a SAN Router with a list of iSCSI devices (access control list) allowed to connect - Automatic Addition and Manual Configuration. To configure devices, select Configuration>iSCSI>Devices. The iSCSI Devices dialog box appears (Figure 5-7 on page 5-15).

  • Page 122: Adding Iscsi Devices Manually

    Configuring iSCSI Devices NOTE: This dialog box appears only if the software package supports iSCSI. When an iSCSI initiator attempts a login, an entry automatically appears in this dialog box when you refresh the screen using the F5 key. If the login from the Initiator includes an iSCSI Alias, it will overwrite any manually configured iSCSI alias.

  • Page 123: Iscsi Devices Dialog Box

    Configuring iSCSI Devices 4. On the iSCSI Initiator, start the iSCSI login process. Some initiators may provide a button to initiate a login; others may require a reboot of the initiator. Messages should appear in the Element Manager Message Log, indicating that the initiator has registered with the name server on the SAN Router.
  • Page 124 Configuring iSCSI Devices 8. Type in the iSCSI identifier, IP address of the iSCSI device, target port, SAN Router port, role and iSCSI alias (optional), and other information in the respective fields. iSCSI Identifier is the iSCSI Initiator Name that you copied in step If it was user-configurable, make sure it matches the name configured on the server.

  • Page 125: Iscsi Devices Dialog Box Options And Data

    Configuring iSCSI Devices iSCSI Devices Dialog Box Options and Data The following describes the fields in the iSCSI Devices dialog box where you can input information. • Enable - Select this to register the iSCSI device with the name service. •...
  • Page 126 Configuring iSCSI Devices You cannot edit the remaining columns of the iSCSI device table. They show the SAN Router storage information associated with each iSCSI device. The iSCSI devices are registered in the mSNS as if they were FC devices. Each iSCSI device is registered as a different FC node.

  • Page 127: Zoning Iscsi Devices

    Zoning iSCSI Devices Zoning iSCSI Devices Zoning is the process of controlling which targets are accessible to the initiator. Targets could have one or multiple LUNs. SAN Routers support LUN mapping/masking capabilities within the SAN Router for iSCSI initiators. If you want to leverage the LUN Mapping/Masking feature, use the following procedure.

  • Page 128: Zoning With Lun Mapping/Masking

    Zoning iSCSI Devices 6. Select the newly-created zone and the iSCSI initiator (WebServer) and click Add. With the newly-created zone selected, select each storage device you want the iSCSI initiator to access, and click Add. 7. Click Commit to save the changes to flash. NOTE: The iSCSI device you added in Element Manager automatically appears in the Devices tree of the mSAN Configuration screen under the appropriate SAN Router port that it was configured for.

  • Page 129: Msan Configuration Window

    Zoning iSCSI Devices Setting Up a LUN Map and Mask 1. In the mSAN Configuration window, click New Zone to display the New Zone dialog box. 2. In the New Zone dialog box, type a zone name. 3. Select the newly-created zone and the FC Target with multiple LUNs that you want the iSCSI Initiator to access, and click Add.

  • Page 130: Lun Mapping/Masking Dialog Box

    Zoning iSCSI Devices 6. Add the iSCSI initiator to the new zone. The new changes are visible in the mSAN Configuration window, as shown in Figure 5-11 on page 5-23. LUN Mapping/Masking Dialog Box Figure 5-10 CAUTION Adding a storage device with multiple LUNs to a zone that has initiators exposes all LUNs to the initiator.

  • Page 131: Lun Mapping/Masking Dialog Box

    Zoning iSCSI Devices Figure 5-11 LUN Mapping/Masking Dialog Box 7. Click Commit to save the changes to flash. Now the iSCSI initiator will be able to login to the FC target and recognize the selected LUNs. Figure 5-12 on page 5-24 shows the three LUNs visible through the Windows 2000 disk management function.

  • Page 132: Computer Management Window

    Zoning iSCSI Devices Computer Management Window Figure 5-12 CAUTION Changing the number of LUNs for a zoned target deletes the LUN map and forces the SAN Router to expose all LUNs to any initiators in the zone. To avoid this, remove the initiators from the zone before you change the number of LUNs on the target, and add the initiators back to the zone with appropriate permissions.

  • Page 133: Configuring Iscsi Authentication

    Configuring iSCSI Authentication Configuring iSCSI Authentication SAN Routers support CHAP-based authentication of iSCSI initiators in conjunction with an external RADIUS server. Challenge Handshake Authentication Protocol (CHAP) provides a type of authentication between an agent (typically a network server) and the client program. Both share a predefined secret, which they verify during an authentication login sequence.

  • Page 134: Sample Authentication Configuration

    Configuring iSCSI Authentication Sample Authentication Configuration Figure 5-13 A typical interaction would be as follows: 1. The iSCSI initiator creates a “portal” session with the SAN Router. 2. The iSCSI initiator is configured to use CHAP authentication. The password and username have been configured in the iSCSI initiator.

  • Page 135: Using Static Routes

    Configuring iSCSI Authentication Using Static Routes If your RADIUS server is attached via the SAN Router's management port, then you need to add a static route to the RADIUS server to reach the TCP port's internal address. Refer to Figure 5-14 page 5-27.

  • Page 136: Using Radius Authentication

    Configuring iSCSI Authentication If you are having problems authenticating iSCSI login requests, make sure that the RADIUS server has logical connectivity to the iSCSI port address. You can confirm this with a ping to the internal address from the RADIUS server (ping 10.10.10.11). If the ping fails, iSCSI initiator will never receive the authentication grant.

  • Page 137: Advanced Tcp Configuration

    Configuring iSCSI Authentication 3. Enter the UDP port on the RADIUS server to send the authentication requests. The RFC 2865 defaults this port to 1812, but can be different for other implementations. 4. Enter the timeout value in seconds. This is the timeout for each retry.

  • Page 138: Configuring The Iscsi Initiator For Authentication

    Configuring iSCSI Authentication 7. Choose Save Configuration to Flash from the File menu to permanently save the configuration to flash memory. Configuring the iSCSI Initiator for Authentication Refer to the documentation of your iSCSI initiator for instructions on setting up the initiator for CHAP authentication. Following is a procedure for using the Microsoft iSCSI initiator.

  • Page 139: Add Target Portal Advanced Settings Dialog Box

    Configuring iSCSI Authentication Add Target Portal Advanced Settings Dialog Box Figure 5-18 3. Enter a user name. Make sure that the Target secret matches the Password and Secret in the user and clients.conf file, if you are using the freeRADIUS RADIUS server. 4.

  • Page 140: Supported Radius Server Configurations

    Configuring iSCSI Authentication • Verify that the target displays on the iSCSI Initiator Properties dialog box as “connected.” If it doesn’t, you must check the storage array for configuration problems. • After you verify that an active session exists for the target, check the message log of the bottom of the Element Manager window on the SAN Router with the iSCSI port.

  • Page 141: Radius Server Located On The Iscsi Subnet

    Configuring iSCSI Authentication RADIUS Server Located on the iSCSI Subnet Figure 5-19 Configuring iSCSI Connections 5-33...

  • Page 142: Radius Server Configuration Dialog Box

    Configuring iSCSI Authentication Figure 5-20 shows an example of the associated RADIUS Server Configuration dialog box in the Element Manager. Display this dialog box by selecting RADIUS Server Configuration under the Configuration menu, iSCSI submenu. Figure 5-20 RADIUS Server Configuration Dialog Box Configuration 3 - RADIUS Server Located on the Same Subnet as the Management Port In this configuration, the RADIUS server is on the same subnet as the SAN Router's 10/100 management port (refer to...

  • Page 143: Radius Server Located On The Management Subnet

    Configuring iSCSI Authentication RADIUS Server Located on the Management Subnet Figure 5-21 Note that you need to add a static route to the RADIUS server that tells the IP stack on the RADIUS server that the path to the iSCSI port of the SAN Router is through its management port IP address.

  • Page 144: Radius Server Configuration Dialog Box

    Configuring iSCSI Authentication RADIUS Server Configuration Dialog Box Figure 5-22 Configuration 4 - RADIUS Server Located One Hop from Management Subnet In this configuration, the RADIUS server is on a subnet that is one hop away from the SAN Router's 10/100 management subnet (refer Figure 5-23 on page 5-37).

  • Page 145: Radius Server Located One Hop From Management Port

    Configuring iSCSI Authentication RADIUS Server Located One Hop from Management Port Figure 5-23 Figure 5-24 on page 5-38 shows an example of the associated RADIUS Server Configuration dialog box in the Element Manager. Display this dialog box by selecting RADIUS Server Configuration under the Configuration menu, iSCSI submenu.

  • Page 146: Radius Server Configuration Dialog Box

    Configuring iSCSI Authentication Figure 5-24 RADIUS Server Configuration Dialog Box If the RADIUS Server resides on a subnet that cannot be directly accessed from the SAN Router, establish a static route path between the server and the SAN Router. The Static Route Table (Table 5-1) shows all necessary static routes in this example.

  • Page 147: Add Static Route Dialog Box

    Configuring iSCSI Authentication Figure 5-25 Add Static Route Dialog Box Configuration 5 - Unsupported Case, RADIUS Server Located on Alternate TCP Port In this configuration, the RADIUS server is on a subnet that is reachable only via a different iSCSI-capable port (refer to Figure 5-26 on page 5-40).

  • Page 148: Radius Server Located On Alternate Tcp Port

    Configuring iSCSI Authentication RADIUS Server Located on Alternate TCP Port Figure 5-26 The primary and secondary RADIUS servers can be connected in any combination of the supported configurations. For example, the primary RADIUS server can be located on iSCSI port's subnet while the secondary RADIUS server can be located on iFCP subnet.

  • Page 149: Monitoring San Router Operation And Connections

    Monitoring SAN Router Operation and Connections This chapter provides details on how to monitor SAN Router performance and operation in the network using Element Manager. Use the following links to move through the chapter. Section Page Using the Element Manager Tools 6-14 Viewing Statistics Monitoring SAN Router Operation and Connections...

  • Page 150: Using The Element Manager Tools

    Using the Element Manager Tools Using the Element Manager Tools The device view in the Element Manager screen portrays the status of Device View the SAN Router, current as of the most recent poll. Shown below is the Device View. Device View for the SAN Router Figure 6-1 Each port is represented by an icon that shows the port type,...

  • Page 151: Color Legend Window

    Using the Element Manager Tools Color Legend window Figure 6-2 Table 6-1 lists the meaning of the port LEDs, fan, and temperature LED and Icon Colors icon colors in the Device View. A single LED by each port indicates port status. Port LED Colors Table 6-1 LED Label...

  • Page 152: Eclipse 2640 Port Border Colors In The Device View

    Using the Element Manager Tools The following table defines the meaning of the colored borders Port Border Colors around the FC, TCP, and management port icons in the Device View. Eclipse 2640 Port Border Colors in the Device View Table 6-2 Port Border Color Meaning...

  • Page 153: Fc Port Tool Tip

    Using the Element Manager Tools FC Port Tool Tip Figure 6-3 FC R_Port Tool Tip Figure 6-4 Monitoring SAN Router Operation and Connections...

  • Page 154: System Information

    Using the Element Manager Tools iFCP Tool Tip Figure 6-5 The System Information panel in the Device View (Figure 6-6) displays System Information the operating conditions of the SAN Router as of the most recent poll. System Information Panel Figure 6-6 Eclipse™...

  • Page 155: System Status Leds

    Using the Element Manager Tools LEDs on the Device View indicate status of system components. Operational Status Table 6-3 System Status LEDs LED Label Color Meaning Power The colored borders around the two icons labeled Power Supplies Supplies monitor the two power supplies. If green, good DC power is being provided by the respective power supply.

  • Page 156: Performance Bar Tool Tip

    Using the Element Manager Tools Figure 6-7 Performance Bar Tool Tip The background color of the bar is dark gray if rate limiting is not configured and lighter gray when configured to limit bandwidth usage. Likewise, if a TCP port is configured to limit traffic to a T3 state, the background color is light gray.

  • Page 157: System Temperature Tool Tip

    Using the Element Manager Tools System Temperature Tool Tip Figure 6-8 Power Supply Tool Tip Figure 6-9 Monitoring SAN Router Operation and Connections...

  • Page 158: Fan Tool Tip

    Using the Element Manager Tools Fan Tool Tip Figure 6-10 Error conditions, warnings, configuration changes, and SAN Router Message Log state change information are all displayed in the Message Log (Figure 6-11). The Message Log is not persistent and there is no history of the transactions.

  • Page 159: Setting The Polling Interval

    Using the Element Manager Tools Message Colors and meanings Table 6-4 Color Meaning Error condition Amber Warning Blue Change applied in a configuration dialog box Black Information To control the content in the Message Log, follow these instructions: 1. Right-click to display the Message Log menu. 2.

  • Page 160: Using The System Log

    Using the Element Manager Tools Figure 6-12 Poll Interval Dialog Box 2. Drag the pointer to the required interval. As you do, the new interval appears in the text box. 3. Click OK to make the change. Using the System Log The System Log (different from the Element Manager Message Log) contains errors or warning states encountered at the SAN Router.

  • Page 161: Network Utilities Dialog Box

    Using the Element Manager Tools Network Utilities Dialog Box Figure 6-13 2. Select iFCP/iSCSI ping TCP to execute a ping that egresses a TCP port. 3. Enter the following in the Enter Options box. DNS names are not supported. -p port [-c count] [-s size] host Ping Options for iFCP Capable Ports Table 6-5 Item...

  • Page 162: Viewing Statistics

    Viewing Statistics Viewing Statistics You can view various accumulated statistics in table format using the Element Manager Statistics/Info menu. The types of statistics collected include: • GE Port Statistics • FC Port Statistics • Port Traffic Statistics • iFCP Port Compression Report •...

  • Page 163: Ge Port Statistics Dialog Box

    Viewing Statistics GE Port Statistics Dialog Box Figure 6-14 Status information in the GE Port Statistics dialog box is described in Table 6-6. NOTE: Port statistic counters, such as RX octets, TX octets, and errors, can be reset (via the Reset button) to a baseline count of zero and have the difference displayed between this new baseline and subsequent polls.
  • Page 164 Viewing Statistics Table 6-6 Gigabit Ethernet/Port Statistics (Continued) Item Meaning Link state The state of Link Detect on the interface (up or no signal detected). STP state Enable or Disable STP protocol on the port. Port state Enable (1) and Disable (2) control for the interface. Frame Accounting •...
  • Page 165 Viewing Statistics Table 6-6 Gigabit Ethernet/Port Statistics (Continued) Item Meaning RMON (EtherStats) • Undersize packets - The total number of packets received that (continued) were less than 64 octets long (excluding framing bits, but including FCS octets) and were otherwise well formed. •...

  • Page 166: Fibre Channel/Port Statistics

    Viewing Statistics Fibre Channel/Port Statistics Select Statistics/Info>FC Port Statistics to display the FC Port Statistics dialog box Figure 6-15 on page 6-18.This displays the statistics for all FC ports on the SAN Router. Statistics displayed in the FC Port Statistics dialog box are described in Table 6-7 on page 6-19.

  • Page 167: Fc Port Status Information

    Viewing Statistics Table 6-7 FC Port Status Information Item Meaning Port Information Port Type R_Port, FC-Auto Port, F Port, L Port, or FL Port. Port Name User-supplied label to identify the port. Port Operational State Up, Down, No signal detected, or Needs Reboot. Port ID P3-byte FCID;...

  • Page 168: Fibre Channel/Device Properties

    Viewing Statistics Fibre Channel/Device Properties To view information on the devices attached to every FC port on the SAN Router, select Statistics/Info>Fibre Channel>Device Properties. The FC Device Properties dialog box appears (Figure 6-16). FC Device Properties Screen Figure 6-16 Table 6-8 describes the Fibre Channel Device Properties information: Fibre Channel Device Properties Report Table 6-8...

  • Page 169: Port Traffic Statistics

    Viewing Statistics Table 6-8 Fibre Channel Device Properties Report (Continued) Item Meaning Device ID The loop ID of the attached device. This is the third byte of the three-byte Fibre Channel ID. Status For an arbitrated loop; it tells whether the device is Enabled or Bypassed.

  • Page 170: Port Traffic Report

    Viewing Statistics Port Traffic Report Figure 6-17 The Port Traffic Report shows a recent history of traffic volume, in megabytes per second for FC ports and megabits per second for There is one graph for each port with two lines on each graph. Different colors are used in the FC and IP graphs.

  • Page 171: Chart Options Dialog Box

    Viewing Statistics 2. Click the Options button to display the Chart Options dialog box (Figure 6-18 on page 6-23). Chart Options Dialog Box Figure 6-18 3. Click seconds or minutes, then use the arrow keys or mouse to adjust the slide bar to change the poll interval and the number of intervals to be displayed in each graph on the Port Traffic Report.

  • Page 172: Ifcp Port Compression Report

    Viewing Statistics iFCP Port Compression Report The iFCP Port Compression Report shows a recent history of compressed traffic volume for each iFCP port on the SAN Router. To display the iFCP port compression report, follow these instructions: 1. Choose Statistics/Info>iFCP Compression Rates to display the iFCP Port Compression Report dialog box (Figure 6-19(.
  • Page 173 Viewing Statistics • Compression Ratio conveys how “effectively” compression is working on the data. The ratio changes based on the data that is passing through the port at any given time and applies only to iFCP frames. For transmitted data, the Compression Ratio is displayed in the format “Original Data (uncompressed data): Compressed Data”;...

  • Page 174: Mac Forwarding

    Viewing Statistics Figure 6-20 Chart Options Dialog Box 3. Click seconds or minutes, and use the arrow keys or mouse to adjust the slide bar to change the poll interval and the number of intervals to be displayed in each graph on the iFCP Port Compression Report.

  • Page 175: Mac Forward Table Dialog Box

    Viewing Statistics Figure 6-21 MAC Forward Table Dialog Box Click the Options button to configure the data refresh rate in seconds. Also known as the Forwarding Database for Transparent Bridges, this is a table of information about unicast entries for which the SAN Router has forwarding and/or filtering information.

  • Page 176: Ip Forwarding

    Viewing Statistics MAC Forwarding Report Table 6-9 Item Meaning MAC Address The MAC address for which the SAN Router has forwarding and/or filtering information. Port The port number on which the MAC address was learned. A value of 0 indicates the MAC address was not learned but that the SAN Router does have some forwarding/filtering information about this address.

  • Page 177: Ip Forward Table Dialog Box

    Viewing Statistics IP Forward Table Dialog Box Figure 6-22 Click the Options button to configure the data refresh rate in seconds. Table 6-10 describes information displayed in the IP Forward Table about the IP addresses learned and/or configured for each port. IP Forwarding Table 6-10 Item...

  • Page 178: Arp (Address Resolution Protocol) Table

    Viewing Statistics ARP (Address Resolution Protocol) Table The ARP Table dialog box (Figure 6-23) contains the active mapping of Ethernet MAC addresses to IP addresses for the SAN Router. To display this dialog box, choose ARP Table from the Statistics/Info menu to display: Figure 6-23 ARP Table Dialog Box...

  • Page 179: Metro Storage Name Server (Msns)

    Viewing Statistics ARP Table Table 6-11 Item Meaning Port The port number associated with the IP address/MAC address pair. MAC Address The MAC address associated with the IP address. IP Address The IP address associated with the MAC address. Mapping Type The type of mapping between the IP and MAC address.

  • Page 180: Storage Name Server (Msns) Report Dialog Box

    Viewing Statistics Figure 6-24 Storage Name Server (mSNS) Report Dialog Box Eclipse™ 2640 SAN Router Administration and Configuration Manual 6-32...

  • Page 181: Remote Connection Statistics

    Viewing Statistics Table 6-12 describes information that appears in the mSNS report. Table 6-12 mSNS Report Item Meaning Port WWN FC WWN for each storage device port or switch port in the fabric. Port ID FC port ID address, in hexadecimal format, for the storage device or switch port.

  • Page 182: Remote Connection Statistics Dialog Box

    Viewing Statistics Remote Connection Statistics Dialog Box Figure 6-25 The Remote Connection Statistics report shows traffic volume and errors for each iFCP connection from this SAN Router. All charts are line charts with one line per remote connection. All configured and enabled remote connections are included in the legend.

  • Page 183: Remote Connection Statistics Report

    Viewing Statistics Remote Connection Statistics Report Table 6-13 Item Meaning Transmit Traffic The average data rate sent to the remote SAN Router over the previous polling interval, in megabytes per seconds. Receive Traffic The average data rate received from the remote SAN Router over the previous polling interval, in megabytes per seconds.

  • Page 184: Chart Options Dialog Box

    Viewing Statistics 2. Click the Options button to display the Chart Options dialog box (Figure 6-26 on page 6-36). Use this dialog box to change the polling interval and the number of displayed intervals. The default polling interval is five (5) seconds. Figure 6-26 Chart Options Dialog Box NOTE: The polling interval and chart options are saved if you close and...
  • Page 185 Viewing Statistics The SAN Router stores information in counters with a maximum Wrapping Counters value of four billion. When this value is reached, the counter resets to zero and the count begins again. When reporting statistics such as the number of bytes received or transmitted, the counter can quickly fill if the port is operating at full line rate.
  • Page 186 Viewing Statistics Eclipse™ 2640 SAN Router Administration and Configuration Manual 6-38...

  • Page 187: Configuration, Firmware, And System Log Maintenance

    Configuration, Firmware, and System Log Maintenance This chapter includes information for upgrading firmware, backing up and restoring configuration data, and retrieving and clearing the system log. Use the following links to move through the chapter. Section Page Upgrading Firmware (E/OSi) Upgrading bootrom (E/OSi) Resetting the System Factory Default Settings for the SAN Router...

  • Page 188: Upgrading Firmware (E/Osi)

    Upgrading Firmware (E/OSi) Upgrading Firmware (E/OSi) Use the following steps to upgrade firmware on the SAN Router. Note that you may also need to upgrade the bootrom file if you have any other version installed. To determine if you need to upgrade bootrom and for instructions refer to Upgrading bootrom (E/OSi) page 7-5.

  • Page 189: Activate Boot Location Dialog Box

    Upgrading Firmware (E/OSi) The dialog box shows the previous version, build date, the active/inactive status of both firmware locations. The TFTP server address and file name are blank the first time the dialog box appears. If the dialog is displayed again later, the last contents are displayed.
  • Page 190 Upgrading Firmware (E/OSi) 5. Close and restart the web browser to load the Element Manager from the new version. After resetting the SAN Router, it may take two or three minutes for the SAN Router’s embedded web server to become ready. Restoring Prior Firmware Version To restore the prior firmware version in the event you experience problems on the network with the new version, use the following...

  • Page 191: Upgrading Bootrom (E/Osi)

    Upgrading bootrom (E/OSi) Upgrading bootrom (E/OSi) You can use the CLI or Element Manager to download and install bootrom to the SAN Router. The following instructions are for using the Element Manager. 1. To determine if the bootrom installed on your system requires an upgrade: •...

  • Page 192: Resetting The System

    Resetting the System Resetting the System Certain configuration changes require you to reset the SAN Router before the changes take effect. Use File>Reset System from the Element Manager Window. These occurrences are described in previous chapters and are listed below for reference. Table 7-2 Resetting the System Dialog Box...
  • Page 193 Resetting the System • Reset SAN Router - This resets the hardware and firmware while maintaining the existing configuration values. Be sure to select this option if you want to maintain any values you have set through configuration dialog boxes. •...

  • Page 194: Factory Default Settings For The San Router

    Factory Default Settings for the SAN Router Factory Default Settings for the SAN Router The following table lists the default settings for parameters that you can configure through the SAN Router Element Manager dialog boxes and the menu path for changing these settings. Table 7-3 Default Element Manager Parameter Settings Parameter...
  • Page 195 Factory Default Settings for the SAN Router Table 7-3 Default Element Manager Parameter Settings (Continued) Parameter Default Setting Menu Path Multi-function port type Fibre Channel Configuration>Port>FC/Ethernet Port Speed Auto Configuration>Port>FC/Ethernet Port State Enabled Configuration>Port>FC/Ethernet Port Parameters FC-Auto Configuration>Port>FC/Ethernet Advanced E_D_TOV - Error Detection (sec) Configuration>Port>Advanced FC Port R_A_TOV - Resource Allocation (sec) Configuration>Port>Advanced FC Port...
  • Page 196 Factory Default Settings for the SAN Router Table 7-3 Default Element Manager Parameter Settings (Continued) Parameter Default Setting Menu Path iSCSI parameters Selective ACKnowledgement Disabled Configuration>Port>FC/Ethernet>Advanced Large PDU Enabled Configuration>Port>FC/Ethernet>Advanced Initial R2T Enabled Configuration>Port>FC/Ethernet>Advanced Store and Forward Disabled Configuration>Port>FC/Ethernet>Advanced Target Read Padding Disabled Configuration>Port>FC/Ethernet>Advanced Target Write Padding...

  • Page 197: Default Element Manager Parameter Settings

    If the SAN Router is shipped in a cabinet, then the default IP address will be 10.xx.yy.zz where, xx is the cabinet number (1, 2, 3, etc.) yy is the product type identifier (16 for the Eclipse 2640 SAN Router) zz is the position in the rack, bottom to top (1, 2, 3, etc.)

  • Page 198: Configuring Backup And Restore

    Configuring Backup and Restore Configuring Backup and Restore CAUTION You must backup the SAN Router configuration periodically so that you can restore the configuration in the event of a hardware failure or problems because of new configuration/software version. The backup function copies all current settings, including zoning, configured on the SAN Router to the TFTP server.

  • Page 199: Restore

    Configuring Backup and Restore 3. Enter the name of the file where the backup file will be stored. If you are entering a new file name, you must place it in an existing subdirectory of the TFTP root directory. The name may include a path if needed.

  • Page 200: Retrieving And Clearing The System Log

    Retrieving and Clearing the System Log Retrieving and Clearing the System Log The System Log (different from the Element Manager Message Log) contains errors or warning states encountered at the SAN Router. The System Log information will be routinely requested by Technical Support whenever you report a problem.

  • Page 201: Delete The System Log

    Retrieving and Clearing the System Log Figure 7-7 Delete the System Log 6. Click OK to empty the System Log. Deleting the system log contents avoids saving duplicate data the next time the log is retrieved. Configuration, Firmware, and System Log Maintenance 7-15...
  • Page 202 Retrieving and Clearing the System Log Eclipse™ 2640 SAN Router Administration and Configuration Manual 7-16...

  • Page 203: Chapter 8 Troubleshooting

    Troubleshooting This chapter gives the troubleshooting procedures for the Element Manager and the SAN Router. Use the following links to move through this chapter. Section Page Element Manager Troubleshooting SAN Router Troubleshooting Troubleshooting...

  • Page 204: Element Manager Troubleshooting

    Element Manager Troubleshooting Element Manager Troubleshooting Table 8-1 on page 8-2 to troubleshoot problems you are having with the Element Manager application. Element Manager Problems and Solutions Table 8-1 Problem Meaning and Solution HTML Login page does not appear. The browser error message: Could not reach the destination IP address or a page not found error or a DNS error.
  • Page 205 Element Manager Troubleshooting Table 8-1 Element Manager Problems and Solutions (Continued) Problem Meaning and Solution Login applet within the HTML Login page You can verify whether the correct version of the Java plug-in is installed by displaying does not appear or takes a long time to the Windows Control Panel.
  • Page 206 Element Manager Troubleshooting Table 8-1 Element Manager Problems and Solutions (Continued) Problem Meaning and Solution Element Manager does not start on If the Java plug-in is installed but not integrated with Netscape, Netscape stops with a Solaris with Netscape. black background and the logo displayed, but only a blank gray rectangle appears where the login button should be.

  • Page 207: San Router Troubleshooting

    SAN Router Troubleshooting SAN Router Troubleshooting Use the following table to troubleshoot SAN Router problems, including configuration problems, through the Element Manager. Table 8-2 SAN Router Problems and Solutions Problem Meaning and Solution A yellow border appears around one of This indicates that the port is not properly configured or the port has been disabled.
  • Page 208 SAN Router Troubleshooting Table 8-2 SAN Router Problems and Solutions (Continued) Problem Meaning and Solution After setting up iFCP configuration, • Check both iFCP ports and make sure you have link lights between the port and remote devices are not displayed. the SAN Router/FC/R switch on either side.
  • Page 209 SAN Router Troubleshooting Table 8-2 SAN Router Problems and Solutions (Continued) Problem Meaning and Solution You aren’t sure which FC port type to FC port parameters that you can configure through the FC/Ethernet Port Configuration assign. dialog box in the Element Manager include: •...
  • Page 210 SAN Router Troubleshooting Eclipse™ 2640 SAN Router Administration and Configuration Manual...
  • Page 211 Glossary • American National Standard Dictionary for Information Systems (ANSI X3.172-1990), copyright 1990 by the American National Standards Institute (ANSI). Copies can be purchased from the American National Standards Institute, 25 West 42nd Street, New York, NY 10036. Definitions from this text are identified by (A). •...
  • Page 212 Glossary NUMERICS A data encoding scheme developed by IBM, translating byte-wide 8B/10B data to an encoded 10-bit format. An implementation of the Institute of Electrical and Electronics 10BaseT Engineers (IEEE) Ethernet standard on 24-gauge unshielded twisted-pair wiring, a baseband medium at 10 Mbps. An implementation of the Institute of Electrical and Electronics 100BaseT Engineers (IEEE) Ethernet standard on 24-gauge unshielded...
  • Page 213 Glossary AC. Electric current that reverses direction at regular sinusoidal alternating current intervals (D). Contrast with direct current. See volts alternating current. See also alternating current/direct current converter. AC/DC converter. A type of electronic equipment that changes AC alternating energy into DC energy. Used as power sources in all modern current/direct current electronic equipment.
  • Page 214 Glossary such as implementing the lower-layer Fibre Channel protocol (FC-0). They are particularly suited to sending video and audio information, as well as text. ASICs differ from general-purpose devices such as memory chips or microprocessors. One of the three connection topologies offered by Fibre Channel arbitrated loop protocol.
