Gigabit Ethernet Diagnostic Program (Gbit) - McDATA ULTRANETTM EDGE STORAGE ROUTER 3000 User Manual

Gigabit Ethernet
Diagnostic Program
(GBIT)
{ Dest Adrs 000088004FEE
110000 120000 }
{ Internal BUFFER_MEM
{ ENET#1:B#5/D#01:PCI#0: E0000000 Enet Adrs
000088005672 }
{ Dest Adrs 000088005672 600000 800000 102000 112000
122000 }
{ Internal HOST_MEM
{ ENA_POLL NO_UFLO
{ Ethernet F/D_MODE
2nd_ENET_RX/TX }
0. Exit Diagnostic
1. Set Options
2. Set Parameters
3. Loopback Test
4. Lpbk Incr Byte Test
5. Lpbk Incr Packet Test
6. Lpbk Chained Pkt Test
7. Port to Port Test
8. Port Incr Byte Test
9. Port Incr Packet Test
10. Port Chained Pkt Test
11. P2P Dual Dir Test
12. P2P DDir Incr Byte
-> 99
Loopback Test running...
***** PASSED--- Loopback Test
failed = 0
Lpbk Incr Byte Test running...
***** PASSED--- Lpbk Incr Byte Test
failed = 0
Lpbk Incr Packet Test running...
***** PASSED--- Lpbk Incr Packet Test
failed = 0
Lpbk Chained Pkt Test running...
***** PASSED--- Lpbk Chained Pkt Test
failed = 0
The UltraNet Edge 3000 Gigabit Ethernet diagnostic program resides
on the UltraNet Edge 3000's flash drive as the file gbit.dll. Using the
PROM interface, the file must be loaded into memory and executed
from there.
This program tests the UltraNet Edge 3000's on-board Gigabit
Ethernet interface and verifies that it can perform memory transfer
functions across the primary PCI bus and local memory. Test data can
be looped back either internally or externally.
UltraNet Edge 3000 Diagnostic Programs
40000100 42000100
MII 100_Mb }
10BT 10_Mb }
MEM_CONT }
ENA_INT 1st_ENET_TX/RX
13. P2P DDir Incr Pkt
14. P2P DDir Chained Pkts
15. TX Line Test
16. RX Line Test
17. TX Ln Incr Byte Test
18. RX Ln Incr Byte Test
19. TX Ln Incr Pkt Test
20. RX Ln Incr Pkt Test
77. Debug Utilities
96. Run All P2P Tests
97. Run All TX Line Tsts
98. Run All RX Line Tsts
99. Execute All Loopback
Troubleshooting and Diagnostics
100000
passed = 1,
passed = 1,
passed = 1,
passed = 1,
13-25
13
