9. To configure IP Management over this circuit, check Set, enter the
IP Address, and the Subnet Mask.
NOTE: If you are using the ATM WAN Configuration Worksheet
Appendix J
for a 1x1 or 2x1 configuration, enter the IP Management address
labeled for Node10.
For a 2x2 or 1x2 configuration, enter the IP Management address labeled
for Node10.
The IP address must be different than the Ethernet Maintenance
Interface address.
10. Click Next>.
The ATM Circuit Wizard - Node20 - Choose Interface dialog box
appears (Node20 is the destination node).
This drop-down menu displays the available ATM interface
providers in the UltraNet Edge Storage Router box for Node20.
Configuring an E_Port Extension over an ATM WAN
Configuring a 1x1 ATM Wide Area Network
