2. Click the Static Routes tab.
This screen shows a defined default gateway and a host specific
static route for Node10. During the configuration process, the
default gateway fields are automatically updated when the
Ethernet Maintenance interface is configured via the "Initial
Config" step. The host specific static route fields are updated
when the IP circuit is configured.
3. Click the Node20 tab.
The IP/Static Routes tabs are displayed on the Node20 tab.
4. Click the Static Routes tab.
Verify Static Routes
Default Gateway
Host Specific Static Route
Default Gateway
Host Specific Static Route
Modifying Static Routes
