Setting the Initial
Configuration
The UltraNet ConfigManager automatically assigns a name and
number to each icon that represents the UltraNet Edge Storage
Router - 3000 Series, for example Node10 and Node20.
The node icons and their corresponding names are also displayed
under the NetMap1 heading in the TreeView Area on the left.
Note: When you are performing this part of the
configuration, the PC which has UltraNet ConfigManager
installed on it, must be attached to the same subnet as
the UltraNet Edge 3000 Ethernet maintenance interface.
If this is not possible, refer to the "Manual Configuration
of the Initial IP Settings" procedure in Appendix H.
1. Right click on Node10 and select Set Initial Config from the
menu that appears.
The Initial Network Setup dialog box appears.
The detected UltraNet Edge 3000 will appear in the section
labeled RECEIVED UltraNet Configuration Requests.
Configuring Tape Device Extension
Network Map Area
(Click twice to place
two nodes in the map)
Configuring Tape Device Extension
9
9-13
