Delivering the Configured Network

Setting the Delivery
Properties
• Cancel - Click Cancel to exit the FICON Global Settings Wizard
without saving the configuration changes.
• Help - Click Help, or press F1, to see information about this
dialog.
Now that you have configured a sample network, or if you made
changes to the configuration parameters, you must deliver the
configuration information for each node defined on the active
network map to the actual nodes.
The configuration information can be delivered in two different
ways, File>Deliver Network or File>Delivery Wizard.
The configurations can be delivered via the Maintenance Port IP or
the PPP Port IP. If you do not have direct IP connectivity, use the PPP
option. See "Setting the Delivery Properties" below.
NOTE: If you used the "Manual Configuration of the Initial IP Settings"
procedure in Appendix H, complete the "Update UltraNet ConfigManager
with the Manual Configurations" procedure before delivering the configured
network.
To set the properties for delivery of the network map configurations,
use the following procedure:
1. Right-click the desired node
The Node10 Properties (UltraNet Edge 3000) screen appears.
2. Click on the drop-down menu to select the Delivery Interface.
Delivering the Configured Network
, then select Properties.
