Site Requirements

UltraNet Edge 3000
Chassis Dimensions
appendix provides site-preparation requirements for the
This
UltraNet Edge 3000.
This section provides the chassis dimensions, clearance,
environmental, and power requirements for the UltraNet Edge 3000.
Table A-1 lists the chassis dimensions of the UltraNet Edge 3000 unit.
The UltraNet Edge 3000 can be placed in a stand-alone area or
mounted into an equipment rack.

Physical Dimensions

Table A-1
Dimensions
Height
Width
Depth
Weight

Site Preparation

1.75 inches 44.45 mm
17.50 inches 444.5 mm
14.00 inches 355.6 mm
14.5 pounds 5.4112 kilograms
A
A-1
