McDATA ULTRANETTM EDGE STORAGE ROUTER 3000 User Manual page 10

Contents
Appendix C
Appendix D
Appendix E
Appendix F
Appendix G
x UltraNet™ Edge Storage Router 3000 User Guide
Customer-Supplied Cables and Equipment ....................... B-15
Preventing Damage from Electrostatic Discharge (ESD) ........ B-15
Cables, Connectors, and Adapters
RS-232 Cables with RJ-45 Connector ........................................... C-1
DB Adapters .................................................................................... C-1
Fibre Channel Specifications ......................................................... C-4
Ethernet 10/100 Specifications ..................................................... C-6
Gigabit Ethernet Specifications ..................................................... C-6
OC-3 ATM Specifications .............................................................. C-8
Advanced UCM Configurations
Configuring the Internal McDATA Fibre Channel Switch
Interface ............................................................................................D-1
FCSW Tab (2 port only) ...........................................................D-2
FC Switch Tab............................................................................D-3
Time Synchronization Protocol .....................................................D-6
Configure the Time Synchronization Protocol .....................D-6
Transport CRC Checking ...............................................................D-8
E_Port Disk Streaming Settings ....................................................D-9
Enable/Disable E_Port Disk Streaming ................................D-9
F_Port Disk Streaming Settings ..................................................D-10
Enable/Disable F_Port Disk Streaming ..............................D-10
Modifying Static Routes
Display Static Routes ...................................................................... E-1
Verify Static Routes ......................................................................... E-2
Modify Static Routes ...................................................................... E-4
Add Static Routes ........................................................................... E-4
Delete Static Routes ........................................................................ E-4
Configure SNMP
Adding an SNMP Trap Destination........................................F-6
Deleting an SNMP Destination ...............................................F-6
Sending Test Trap ......................................................................F-6
SNMP Software Packages ...............................................................F-7
Resetting the System to Factory Defaults
Overview of the Sysclean Command ..........................................G-1
Using the Sysclean Command ......................................................G-1
