Setting the Delivery
Properties
To set the properties for delivery of the network map configurations,
use the following procedure:
1. Right-click the desired node
The Node10 Properties (UltraNet Edge 3000) screen appears.
2. Click on the drop-down menu to select the Delivery Interface.
3. The Delivery Interface defines the IP address by which the
network map will be delivered.
4. Select the desired option to deliver the network map
(configurations) to the node(s).
5. Click OK.
6. Repeat these steps for the other node(s).
7. Deliver the network map (configurations) by either the Delivery
Wizard or the Deliver Network option.
Configuring an E_Port Extension over an Ethernet WAN
Delivering the Configured Network
, then select Properties.
5
5-25
