UltraNet Edge 3000 Diagnostic Programs
13
Ethernet Diagnostic
Program (E10T)
McDATA UltraNet Edge 3000 User Guide
13-24
***** PASSED--- Lpbk Interrupt Incr Byte
failed = 0
***** PASSED--- Lpbk Interrupt Incr Byte
failed = 0
Test 12, Lpbk Flow Thru CRC Test running...
***** PASSED--- Lpbk Flow Thru CRC Test
failed = 0
***** PASSED--- Lpbk Flow Thru CRC Test
failed = 0
Test 13, Lpbk TX Gather Test running...
***** PASSED--- Lpbk TX Gather Test
failed = 0
***** PASSED--- Lpbk TX Gather Test
failed = 0
Test 17, LED Visual Blink Test running...
***** PASSED--- LED Visual Blink Test
failed = 0
***** PASSED--- LED Visual Blink Test
failed = 0
*> SBTM Fibre Channel BB Diagnostic Test Rev. 1.1 - May
04, 2003 <*
The UltraNet Edge 3000 10/100 Ethernet diagnostic program resides
on the UltraNet Edge 3000's flash drive as the file e10t.dll. Using the
PROM interface, the file must be loaded into memory and executed
from there.
NOTE: A Serial Connection should be used to run this diagnostic, see "Serial
Interface Connection" in this chapter.
This program tests the UltraNet Edge 3000's the IP WAN interface. It
verifies that it can perform memory transfer functions across the
primary PCI bus and local memory. Test data can be looped back
either internally or externally.
Individual tests can be selected from the menu or the 99. Execute All
Loopback option can be used to run tests 3, 4, 5, and 6.
*> SBTM AMD FAST+ ENET Diagnostic Test Revision 1.1 -
12/07/2001 <*
MAIN MENU
Options={ SINGLE STOP
Run={ }
Parameters={ 5E8 5DA
{*ENET#0:B#3/D#01:PCI#3: D8000000 Enet Adrs
000088004FEE }
0 1 } Total Errors={ 0 } Tests
0 1 01 Random }
passed = 1,
passed = 1,
passed = 1,
passed = 1,
passed = 1,
passed = 1,
passed = 1,
passed = 1,
