SNMP Configuration Screen Fields
Table F-1
Field
Authentication Traps
Default Action
Read Community
4 — Warning condition
5 — Condition is normal but still significant
6 — Informational
7 — Debug-level messages
7. Set the Host Access section to the IP address of the network
management machine.
a. Click the Asterisk (*) to select the Address field and enter a
valid IP address.
b. Select the Action field and set to either Allow or Deny. (This
will allow access to an individual IP address if the Default
Action is set to Deny. See Table F-1 for a detailed description
of these fields.)
8. Click OK.
9. Proceed to the "Delivering the Configured Network" section in
the appropriate configuration chapter to deliver the
configurations files.
NOTE: For more detailed information, see the UltraNet ConfigManager
online Help.
Description
Yes enables the Authentication Traps to be sent to the defined
trap destination.
No disables the Authentication Traps.
This field defines the access rights for all the hosts that are not
specified in the Host Access field in the lower portion of the
screen. It acts as a default setting.
Allow is the default. For example, if you set this field to Deny,
all hosts will be denied access unless they are defined
individually to Allow in the Host Access field below.
Specifies the Read Community. This field can hold up to 255
alphanumeric characters and can be upper and lower case
letters.
