Power Supply Installation Procedure
Top Cover Removal Procedure
Use the following procedure to install the power supply into the
UltraNet Edge 3000.
CAUTION
Attach a wrist strap and follow ESD procedures during the
handling of all electronic components.
Tools Required: No special tools are required.
CAUTION
Make sure power is turned off for the power supply that is being
installed.
1. Remove the new power tray from the antistatic wrapping.
2. Place the power tray into the slot and gently slide it back until it is
connected to the power distribution board at the back of the
UltraNet Edge 3000.
3. Make certain the metal clip has snapped into place holding the
power tray firmly in place.
4. Reconnect the power cords (rear).
5. Turn on the power supplies.
Use the following procedure to remove the top cover from the
UltraNet Edge 3000.
Tools required: A small Phillips screwdriver.
CAUTION
Attach a wrist strap and follow ESD procedures during the
handling of all electronic components.
Power Supply Installation Procedure
Hardware Maintenance
12
12-7
