NOTE: If you do not know what the default gateway (the router IP address
attached to the UltraNet Edge 3000) is at this point, you can add the static
route at a later time. To add static routes at a later time, see Appendix E,
Static Routes.
15. Check Set, enter the IP Address of the router directly attached to
Node20 to set the static route.
NOTE: If you are using the Configuration IP Address Worksheet from Appendix
J, enter the following information:
For Node20, enter the gateway address labeled
2x1 configuration or the 1st circuit of a 2x2 or 1x2.
For the 2nd circuit of a 2x2 or 1x2 configuration, enter the gateway address
labeled .
16. Click Next>.
The IP Circuit Wizard Configure Circuit dialog box appears.
This dialog box enables you to configure the circuit properties.
Configuring an F_Port Extension over an Ethernet WAN
Configuring a 2x2 Ethernet Wide Area Network
for the circuit on a 1x1 or
