Setting the Initial
Configuration
The node icons and their corresponding names are also displayed
under the NetMap1 heading in the TreeView Area on the left.
If you configured an UltraNet Edge 3000 custom chassis (in
4, Building a Custom Edge 3000
process with the "Setting the Initial Configuration" procedure.
NOTE: When you are performing this part of the configuration, the PC
which has UltraNet ConfigManager installed on it, must be attached to the
same subnet as the UltraNet Edge 3000 Ethernet maintenance interface. If this
is not possible, refer to the "Manual Configuration of the Initial IP Settings"
procedure in Appendix H.
1. Right click on Node10 and select Set Initial Config from the
menu that appears.
The Initial Network Setup dialog box appears. The detected
UltraNet Edge 3000 will appear in the section labeled RECEIVED
UltraNet Configuration Requests.
Configuring a 1x1 Ethernet Wide Area Network
Chassis), continue the configuration
Configuring FICON Extension
8
Chapter
8-7
