Unpacking and Inspecting the Hardware

Unpacking and Inspecting the Hardware

UltraNet Edge 3000 Placement

Table-Top

Rack Mount

UltraNet™ Edge Storage Router 3000 User Guide
B-2
Use the following procedure to unpack and inspect your hardware:
1. Cut the tape and open the cardboard covers.
2. Lift the chassis up and out from the cardboard box.
3. Place the unit on a static-free or static-controlled surface.
4. Remove the antistatic wrapping from the UltraNet Edge 3000.
5. Make sure you have all the items listed on the packing list(s). If
any items are missing or broken, please contact your McDATA
representative.
The UltraNet Edge 3000 unit can be placed on a table or mounted in
an equipment rack. Observe all recommended clearances as stated in
"Clearance Requirements" in Appendix A.
Place the UltraNet Edge 3000 unit on a level, stable surface. Do not
place in direct sunlight or near a heat vent.
To install the UltraNet Edge 3000 unit in an equipment rack, use the
rack mount bracket ears and screws shipped with your UltraNet
Edge 3000 unit and proceed as follows.
Tools Required: #2 Phillips screwdriver.
NOTE: Depending on the rack mount type, it may require two people to
mount the UltraNet Edge 3000. One to hold the unit in position while the
other attaches it to the rack mount.
1. Using a #2 Phillips screwdriver and eight 6-32 1/4" flathead
undercut Phillips screws (four for each bracket ear), attach the
two bracket ears to the front corners of the UltraNet Edge 3000
unit.
— For a flush mount, position the brackets even with the front of
the UltraNet Edge 3000 unit and attach them using the holes at
the front of the brackets.
