Replacing the OC-3 ATM Short Wave Transceiver

Removing the OC-3
ATM Short Wave SFP
Transceiver
Removing the Plain
Metal Clasp
Transceiver
This section provides procedures for both removing and installing
the OC-3 ATM short wave transceiver.
Tools required: No special tools are required.
CAUTION
Attach a wrist strap and follow ESD procedures during the
handling of all electronic components.
The transceivers are hot swappable, which means they can be
replaced while the Edge unit is in operation.
CAUTION
Laser radiation is invisible and can damage the eye.
Unterminated optical connectors may emit laser radiation.
Do not view the beam with the naked eye or with optical
instruments. Dust caps and dust covers MUST be left in
place on all unterminated bulkhead receptacles and on the
end of every radiating fiber jumper.
Use the following procedure to remove the short wave OC-3 ATM
transceiver from the (right) port of the interface card. Although the
OC-3 ATM interface card currently has two physical ports, only the
right port is functional.
1. Remove the fiber optic cabling from the transceiver.
2. Lift the metal clasp up.
Replacing the OC-3 ATM Short Wave Transceiver
Hardware Maintenance
