Contents
16.3.10.70 E540 Error code detail There is a fault in the ascent/descent of the tray. .............................. 16-154
16.3.10.71 E577 Error code detail There is a fault in stack processing (counterclockwise direction). .... 16-154
16.3.10.72 E580 Error code detail There is a fault in ascent/descent of the stack tray. .......................... 16-155
16.3.10.73 E584 Error code detail There is a fault in feed operation (No. 2). ......................................... 16-155
16.3.10.74 E5F0 Error code detail There is a fault in paper positioning for the saddle. .......................... 16-156
16.3.10.75 E5F1 Error code detail There is a fault in paper folding for the saddle. ............................... 16-156
16.3.10.76 E5F2 Error code detail There is a fault in the saddle guide. ................................................... 16-157
16.3.10.77 E5F3 Error code detail There is a fault in saddle alignment. ................................................ 16-157
16.3.10.78 E5F4 Error code detail There is a fault in stapling at the saddle rear. ................................... 16-158
16.3.10.79 E5F5 Error code detail There is a fault in stapling at the saddle front. ................................. 16-158
16.3.10.80 E5F6 Error code detail There is a fault in stapling by the saddle paper pushing plate. ......... 16-159
16.3.10.81 E5F8 Error code detail There is a fault in the saddle connector. ........................................... 16-160
16.3.10.82 E5F9 Error code detail There is a fault in the saddle switch. ................................................ 16-160
16.3.10.83 E601-0xdd: after performing [COPIER>ADJUST>V-CONT-Y/M/C/K] to improve
faint image ............................................................................................................................................. 16-161
16.3.10.84 E602-0001/E602-0002/E602-0003 Error Code: Remedy upon occurrence of error code ...... 16-162
16.3.10.85 E602 Error code detail The hard disk is faulty. ...................................................................... 16-163
16.3.10.86 E602-0001 Error code At about 5 sec. after the power is turned ON, due to a failure of the
Distribution Board PCB Ass'y .............................................................................................................. 16-165
16.3.10.87 E602-0001 Error code At about 5 sec. after the power is turned ON, due to a connection
failure of the flat cable between the HDD unit and the main controller ............................................... 16-165
16.3.10.88 E602-0202 Error Code: Recovered after performing HD-CHECK ......................................... 16-166
16.3.10.89 E602-0202 Error Code: Because of faulty SRAM Board PCB ............................................... 16-166
16.3.10.90 Progress bar on machine starting-up window is slower than usual, then E602 Error
Code is displayed ................................................................................................................................... 16-166
16.3.10.91 E602-0402 Error Code: not recovered after replacement of main controller PCB ................. 16-166
16.3.10.92 E602-0x02 Error Code ............................................................................................................. 16-167
16.3.10.93 E602-0001 Error Code ............................................................................................................. 16-167
16.3.10.94 E602-0402 Error Code: At power-on upon installation, iRC3220 .......................................... 16-167
16.3.10.95 E604 Error code detail There is a shortage in image memory (SDRAM). ............................ 16-167
16.3.10.96 E604-0000 Error Code: Because of faulty expansion RAM ................................................... 16-168
16.3.10.97 E605 Error code detail The battery for image memory is faulty. ........................................... 16-168
16.3.10.98 E606 Error code detail The hard disk is faulty. ...................................................................... 16-169
16.3.10.99 E674 Error code detail The fax board is faulty. ..................................................................... 16-169
16.3.10.100 E677-0002 Error Code ........................................................................................................... 16-169
16.3.10.101 E711 Error code detail There is a fault in IPC communication.(DADF-K1) ...................... 16-170
16.3.10.102 E711 Error code detail There is a fault in IPC communication. ........................................... 16-170
16.3.10.103 E712 Error code detail There is a fault in the communication between the ADF
and the reader unit. ................................................................................................................................ 16-171
16.3.10.104 E713 Error code detail There is a fault in the communication between the finisher
and the cassette pedestal. ....................................................................................................................... 16-171
16.3.10.105 E716 Error code detail There is a fault in the communication between the cassette
pedestal and the printer unit. .................................................................................................................. 16-172
16.3.10.106 E716-0000 Error code Recorded only in the error history ................................................... 16-172
16.3.10.107 E717 Error code detail The communication with the NE controller is faulty. ..................... 16-172
16.3.10.108 E719 Error code detail The coin vendor is faulty. ............................................................... 16-173
16.3.10.109 E719-0011 Error code After the cable is disconnected because of a scanning fault
in card reader D1 .................................................................................................................................... 16-173
16.3.10.110 E719-0001 Error code When the coin vendor is disconnected, unable to be cleared ........... 16-174
16.3.10.111 E731 Error code detail There is a fault in the UFR board. .................................................. 16-174
16.3.10.112 E732 Error code detail There is a reader communication error. ........................................... 16-174
16.3.10.113 E732-9999 Error Code: Recorded in error log after performing service mode
COPIER> Function> CLEAR> MN-CON ............................................................................................ 16-175
16.3.10.114 E732-0001 Error code A message 'Starting up. Please wait' keeps displaying for about
