Application This manual has been issued by Canon Inc. for qualified persons to learn technical theory, installation, maintenance, and repair of products. This manual covers all localities where the products are sold. For this reason, there may be information in this manual that does not apply to your locality.
Page 4
This Service Manual contains basic information needed to service the Image Reader-A1/ iR5000i/iR6000i and its accessories (i.e., side paper deck, shift tray) in the field, conducted for the purpose of maintaining its product quality and a specific level of performance. A separate Service Manual is made available for each of its accessories (except for the side pa- per deck and shift tray);...
Enlarge V 1: 4.000 Zoom 1: 0.250 to 4.00 (in 1% increments) Wait time iR5000i: 5 min or less (at 20°C/168°F) iR6000i: 6 min or less (at 20°C/168°F) First copy time 5.1sec (stream reading, right deck, Direct, A4/LTR, non-AE, straight delivery) 3.8 sec (book mode, right deck pickup, Direct, A4/LTR,...
282 Wh consumption Noise (approx.; reference) (approx.; reference) Continuous iR5000i: 979 Wh (approx.; reference only) copying iR6000i: 1008 Wh (approx.; reference only) By sound power level (impulse mode) During copying iR5000i: 71 dB or less iR6000i: 78 dB or less...
CHAPTER 3 INSTALLATION 7. Installing the NE Controller-A1 Installation herein is to the iR5000i/6000i. For how to make various set- tings and points to note and check (operations), see the Installation Proce- dure that comes with the machine. 7.1 Installation...
4) Is the spring of the separation claws displaced? YES: Mount the spring correctly. Print paper, High-voltage transformer, DC controller PCB 5) Try paper of a type recommended by Canon. Is the problem cor- rected? YES: Advise the user to use recommended paper.
YES: The paper may be moist. Advise the user on the correct method of storing paper. 3) Try paper recommended by Canon. Is the problem corrected? YES: Advise the user to use recommended paper. Paper guide, Fixing assembly inlet drive solenoid (SL1) 4) Is the paper guide coated with toner or foreign matter? YES: Clean it with solvent.
