If the message "Non-system disk or disk error" appears, it means the BIOS
o
attempted to boot from the DOC and failed because the operating system is
not yet installed. Restart the workstation and repeat Step 7. When the
workstation boots from the floppy diskette, proceed to the next step.
8.
From the A: command prompt type:
dformat /win:d800 /s:doc42.exb /nopnp
and press [Enter]. Confirm by hitting [Y], [Enter] to start the format
utility.
9.
When the operation is complete, the display prompts "finished xxxx K bytes...
Format complete..."
The Disk On Chip drive letter will be Drive D assuming a hard drive with a
o
single partition is installed. If a hard disk is not installed, it will be Drive C. At
this point, you should be able to type dir d: [Enter] and receive a "File Not
Found" prompt since no files have been copied to the DOC yet.
10.
From the A: command prompt type
sys d: [Enter]
to copy the operating system files from the boot floppy to the Disk On
Chip.
11.
Test the Disk On Chip by pressing the front panel recovery button and restarting
the workstation. After the POST, the workstation should boot from the DOC.
12.
The basic configuration and setup of the M-Systems Disk On Chip is complete
and may be used for your application.
PCWS Eclipse Setup Guide
PCWS Eclipse Hardware Configuration
Installing a Disk On Chip
3-35
