Remove/Replace the System Processor

Remove/Replace the System Processor

The Celeron vs. the Pentium III Processor

When the Eclipse entered production, it could be ordered with either a Celeron
366MHz processor in the Plastic Pin Grid Array (PPGA) package, or a Pentium III
700 MHz processor in the Flip-Chip Grid Array (FC-PGA) package.
In late 2003, the new processor selections became available. The new selections are
either a Celeron 850MHz in the FC-PGA package, or a Pentium III 1 GHz, also in the
FC-PGA package. Figure 3-33, below, points out examples of the PPGA and FC-PGA
packages.
Figure 3-33: The PPGA Celeron and FC-PGA Pentium III Processors
The following table summaries the characteristics of the previous and available
processors for the PCWS Eclipse. The current Pentium III and Celeron selections are
highlighted.
Processor
Pentium III 700 MHz
Pentium III 1 GHz
Celeron C850
Celeron C366
3-24
Package Core
Type Speed
FC-PGA 700MHz
FC-PGA 1 GHz
FC-PGA 850 Mhz
PPGA 366 Mhz
FSB L2
Speed Cache
100 Mhz 256K
100 Mhz 256K
100 Mhz 128K
66 Mhz 128K
