PCWS Eclipse Hardware Configuration

Remove/Replace DIMMs

Remove/Replace DIMMs

The Eclipse System Board includes a pair of Dual-In-Line-Memory Module (DIMM)
Sockets. Sizes of 32M, 64M, 128M, and 256M are supported with a maximum of
512M. Previous editions of this Setup Guide incorrectly state the maximum memory
is 256M. However, 512M DIMMs are not supported.
In production units, MICROS endeavours to populate a single DIMM socket in each
configuration. In other words, a 256M configuration will consist of a single 256M
DIMM instead of 128 DIMMs.

Recommended DIMMs

The table below shows DIMMs that may be purchased from MICROS.
Size
32M
64M
128M
256M

Purchasing DIMMs

The Table shown in Figure 3-27 lists MICROS approved DIMMs for the Eclipse.
64M
700502-165
Viking Interworks
IW-8864x6
3-20
CAUTION
When using 512M memory configuration (2 x 256M), see
FB04-002 for more information and a solution.
Description
PC100 SDRAM +3.3V Unbuffered
PC100 SDRAM +3.3V Unbuffered
PC100 SDRAM +3.3V Unbuffered
PC100 SDRAM +3.3V Unbuffered
Figure 3-26: Recommended DIMM Part Numbers
Eclispe Approved DIMM List
128M
700502-166
Unigen
UG516S6648JT2-PL
PNY
690000978-VA
Viking Interworks
IW-8E64x8 4-P2
Figure 3-27: Approved DIMMs for the Eclipse
MICROS P/N
700502-165
700502-166
700502-167
700502-170
256M
700502-167
Viking Interworks
VI8AU326438CTBM1
PCWS Eclipse Setup Guide
