PCWS Eclipse Hardware Configuration
Remove/Replace DIMMs
The Table shown in Figure 3-30 indicates that you can install DIMMs in various
combinations of sizes to achieve the desired amount of memory, displayed in the right
column.
Figure 3-30: Eclipse System Board DIMM Configuration
Installing DIMMs
1.
Refer to page 3-2 to disassemble the Eclipse Workstation if you have not done so
already.
2.
If you must remove a DIMM to install one with a larger capacity, see the
following section on removing DIMMs.
3-22
STK1
STK2
32M
--
32M
32M
64M
--
64M
32M
64M
64M
128M
--
128M
32M
128M
64M
128M
128M
256M
--
256M
32M
256M
64M
256M
128M
256M
256M
Total
32M
64M
64M
96M
128M
128M
160M
196M
256M
256M
288M
320M
384M
512M
