How This Manual is Organized

PCWS Eclipse Setup Guide
This manual is divided into five chapters, briefly discussed below.
Chapter 1 describes each of the Eclipse components and shows how to
assemble them into a complete workstation. The chapter also provides
specifications, care and handling instructions, and information on how to
connect peripherals to the Front I/O Panel.
Chapter 2 describes how to use the Phoenix BIOS Setup Utility to
configure the Eclipse hardware.
Chapter 3 covers the Eclipse system unit hardware configuration. Topics
include how to remove the cover, identify the major components, and how
to upgrade or configure such items as the main memory, processor, and
hard disk, or to install the optional internal customer display.
Chapter 4 covers the Eclipse LCD\Touchscreen Head configuration.
Topics include how to remove the cover, identify individual components,
and set configuration jumpers for the LCD panel and touchscreen
interface.
Chapter 5 provides basic troubleshooting data in the form of BIOS error
messages and beep codes.
A Reference section consisting of Equipment Dimensions, FCC/DOC
Statement, and Connector/Cable Diagrams can be found at the end of this
manual.
SHOCK HAZARD
No user serviceable parts inside.
Refer servicing to qualified personnel.
