What Is The Eclipse Workstation?

Specifications

Specifications

The PCWS Eclipse workstation conforms to the following specifications.
Specification
Processors
Processor Socket
Cache
Display(s)
Touchscreen
Backlight(s)
DVI/VGA Interface
BIOS
BIOS Setup Utility
Real Time Clock
Memory
Mag Stripe Reader
Customer Displays
USB Ports
LAN Interface
1-8
Parameters
Celeron C850MHz or Pentium III 1GHz
Socket 370
Celeron = 128K L2 cache, Pentium III = 256K
L2 cache,
12.1" TFT LCD, Optional 15" TFT LCD
Elo 12.1" or 15" five-wire resistive, 100
thousand points-per-inch resolution rated at a
screen life of over 35 million touches.
Can be set to one of three intensity levels
through the API
The Front Panel DVI Connector supports
either the LCD Head or standard CRT/LCD
with a custom wired cable.
Phoenix 4.0 BIOS Plug 'n Play DMI 2.0
compliant in flash EPROM, includes updated
LAN boot software to support diskless
workstations.
Configures system time and data, hard drive
parameters, assigns COM and LPT port
resources, and the boot device sequence.
Time-of-day clock: 100-year calendar with
alarm features and century roll-over, includes
256 bytes of battery backed CMOS RAM,
reserved for BIOS use.
Two DIMM sockets support 64 MB to 512 MB
Max (256M Per Slot) of PC100 SDRAM
(+3.3V, Unbuffered)
3-Track ABA compatible, operates in
MAGTEK and Special modes.
Optional 2 x 20 character internal customer
display mounts to rear of system unit and or
optional pole mount 2 x 40 character remote
pole display
Two UHCI 1.1 compliant USB ports
On-board 10/100 Ethernet. Includes MBA
UNDI Version 4.3 Boot ROM
PCWS Eclipse Setup Guide
