What Is The Eclipse Workstation?
The I/O Panel
COM 3 (Reserved for Mag Card Reader)
This port is configured as COM 3. It is reserved for the front panel 3-track card
reader.

Internal Speakers

The I/O Panel includes a pair of jacks for the front mounted speakers. Plug the right
speaker into the top connector and the left speaker into the bottom connector.

USB

The Universal Serial Bus (USB) interface supports the host controller functions with a
built-in Root Hub and 2 USB ports. The USB circuitry is implemented based on
OpenHCI, the Open Host specification for USB.
USB is based on a tiered star topology that runs at a data rate of up to 12Mb per
second. All USB devices are Plug and Play compatible, and can be connected to the
Eclipse when power is on. This means that each device can be recognized without
rebooting the workstation.
The 12Mb/s data rate provides sufficient throughput to support external storage media
such as CD-ROM drives, ZIP drives, and digital scanners and cameras.
The Eclipse fully supports a USB floppy diskette which is capable of booting the
workstation.

Mouse

This port accepts a PS/2 style mouse or other pointing device.

Keyboard

This port accepts a PC keyboard with a PS/2 style connector.

RS232 Serial, DB9 Connector (COM1)

This industry standard DB9 male connector can be used for an external modem, or
other serial peripheral device. This port is supported by an industry standard 16550
UART with a 16-byte receive buffer. BIOS default settings configure this port at
COM1.

Parallel Port

The parallel port is an industry standard Centronics parallel interface. In addition, the
parallel port also supports the EPP and ECP standards.

Digital Visual Interface (DVI) Connector

This connector provides both a standard VGA output for connecting a conventional
CRT monitor (requires a special cable), or supports the Digital Visual Interface (DVI)
interface to the LCD panel.
1-16 PCWS Eclipse Setup Guide
