DIMM Sockets

The Eclipse System Board includes a pair of Dual In Line Memory Module (DIMM)
sockets that allow the workstation to support a maximum of 256M of PC100 SDRAM.
Approved DIMMs are listed in the section on removing and replacing system
memory.

Silicon Image Panel Link Transmitter

This device converts 6-bit RGB pixel data as well as timing signals from the GMCH
into Time Multiplexed Differential Signalling (TMDS) signals. A Panel Link Receiver
in the LCD/Touchscreen Head converts TMDS signals back to the 6-bit RGB format
in order to drive a TFT panel.

Altera POS and IO Controller

The Altera is a Programmable Logic Device (PLD) custom programmed to support
MICROS Point Of Sale and Input/Output features as described below.
• COM1 (No Assignment)
• COM2 (Touchscreen)
• COM3 (Front mounted Mag Stripe Reader)
• COM4 (LCC/IDN)
• LM87 Hardware Monitor
• Watchdog Timer
• 3-Track Magnetic Stripe Reader
• Rear and Remote Customer Display
• MICROS compatible Cash Drawers

IT8702F-A Super IO Controller

This device is attached to the IOCH through a Low Pin Count (LPC) interface. It
performs the following functions on the Eclipse System Board.
• COM5 (No Assignment)
• COM6 (IRQ is Shared with on-board Audio)
• PS/2 Keyboard and Mouse Controller
• IEEE 1284 Parallel Port
• Smart Card Reader Controller
• Processor Fan Speed Controller
