Problem
System Boots from Floppy
Diskette. Does not boot
from or read hard disk.
(LCD Displays a blinking
cursor)
System Boots from Floppy
Diskette. Does not boot
from hard disk, but you can
read hard disk directories
and access data files.
System Boots from Hard
Disk. Does not boot from
Floppy Diskette.
Eclipse does not boot from
LAN.
Eclipse does not boot from
LAN. Patch Cable is
connected. Front panel FD
and LINK LEDs are Off (See
Figure 5-1, and Page 5-5).
PCWS Eclipse Setup Guide
Possible Cause
Bad or disconnected power
or data cable to hard disk.
Disk parameters lost in
CMOS Setup.
Boot Priority not set
correctly.
Hard Disk Translation Mode
Set Incorrectly.
Defective Hard Disk.
Hard disk boot sector lost.
USB Cable not connected.
Boot Sequence not set
correctly.
Patch Cable not connected
Boot Sequence not set
correctly.
Defective Patch Cable at
workstation.
Defective in-wall cabling, or
defective hub/switch or
defective patch cable
connected at hub/switch.
PCWS Eclipse Diagnostics
Basic Troubleshooting
Solution
See Chapter 3 and check
the connections to the hard
disk.
Restart workstation to
restore hard disk
parameters.
Check Boot Priority setting
in CMOS Setup Utility
(Chapter 2).
See Hard Disk Translation
Mode in CMOS Setup
Utility, (Chapter 2).
Replace Hard Disk.
Backup all files and
reformat drive. Restore all
files.
Check USB cable to system
unit.
Check Boot Sequence
setting in CMOS Setup
Utility (Chapter 2).
Connect Network Cables
Check Boot Sequence
setting in CMOS Setup
Utility (Chapter 2).
Replace Patch Cable
Check in-wall cable for
continuity. Check ports on
hub/switch. Check patch
cable at hub/switch.
5-3
