16.
Remove the System Unit chassis cover. Note the pair of clips on the right side of
the system unit as shown on the left side of Figure 3-10. To remove a latch, push
on the upper section while at the same time, lifting the lower section to release it.
Figure 3-10: Removing the System Unit Cover Latches
17.
Open the cover, placing it to the left. Figure 3-11 points out the major internal
components of the Eclipse, which are described in more detail in the following
pages.
PCWS Eclipse Setup Guide
CAUTION
When removing the clips that hold the system unit cover in
place, follow the instructions in the step below to avoid
deforming them.
Figure 3-11: Eclipse System Unit - Cover Open
PCWS Eclipse Hardware Configuration
Disassembling the Eclipse
3-7
