Eclipse LCD/Touchscreen Head Configuration
The LCD/Touchscreen Interface Board
LCD/Touchscreen Interface Board -002 - Connectors
Figure 4-7 shows the connectors located on the -002 board. J3, the TFT LCD
connector will either be covered with tape or not mounted.
Figure 4-7: -002 LCD/Touchscreen Interface Board - Connectors and Jumpers
4-8
PCWS Eclipse Setup Guide
