The original 12.1" DSTN or TFT LCD/Touchscreen head (400497-001 or
o
400497-002) with a 3M MicroTouch Excalibur controller.
The recent 12.1" LCD Head/Touchscreen (400497-003A) with the Hampshire
o
TSHARC touchscreen controller.
The 15" LCD/Touchscreen Head.
o
Tips for Performing the Calibration Procedure
Perform the calibration procedure in the position (sitting or standing) that the
touchscreen is normally used.
Calibrating the MicroTouch TouchWare Drivers
1. From the Desktop, press the MicroTouch TouchWare icon twice. If this is the first
power-up after the LCD/Touchscreen head has been swapped out, you may be
prompted to run the calibration procedure.
2. Select the Calibrate tab.
3. Press the Calibrate button.
Two calibration targets appear on the screen. A hand points to first target, in
o
the lower left quadrant of the screen.
If you press [ESC] or do not touch the screen within 20 seconds, the
o
calibration process aborts with no change in calibration values.
4. The hand points to the first calibration target, in the lower left corner. Position
your fingertip to completely cover the target and touch the screen without letting
go. Continue holding the touch until the message "Touch Enabled" appears.
5. Continue the procedure by repeating Step 4 on the next target.
6. When calibration is complete, a dialog box prompts you to test the calibration.
Drag your finger across the screen and make sure the cursor follows your
o
movements. Touch each corner and touch along each edge of the screen to
verify that the cursor can reach the display area.
If you must re-calibrate, make sure to touch the targets carefully. It is possible
o
that you did not hold the touch long enough, or that you accidently touched
the screen in the wrong place during the calibration procedure.
Calibrating the Hampshire Touchscreen Drivers
1. From the Desktop, select Start -> Programs -> Hampshire Touchscreen Control
Panel.
2. Select the Calibration tab.
Press the [Configure] button to define the calibration type, offset, and target type
in additon to choosing a 3, 4, 7, or 20 point test.
PCWS Eclipse Setup Guide
What Is The Eclipse Workstation?
Operating the Eclipse
1-23
